Chauvin Arnoux, LCD Voltage Indicator, 690V ac/dc Continuity Check, Battery Powered CAT III, P01191743Z

RS Stock No.:: 133-6383
Mfr. Part No.:: P01191743Z
Brand:: Chauvin Arnoux

Chauvin Arnoux, LCD Voltage Indicator, 690V ac/dc Continuity Check, Battery Powered CAT III, P01191743Z

Subtotal (1 unit)*

£64.81

(exc. VAT)

£77.77

(inc. VAT)

FREE delivery for orders over £50.00

In Stock

6 unit(s) ready to ship from another location

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit
1 +	£64.81

*price indicative

RS Stock No.:: 133-6383
Mfr. Part No.:: P01191743Z
Brand:: Chauvin Arnoux

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Chauvin Arnoux
	Product Type	Voltage Indicator
	Continuity Check	Yes
	Display Type	LCD
	RCD Trip Test	Yes
	IP Rating	IP54
	Battery Type	AAA, LR3
	Power Source	Battery
	Weight	200g
	Minimum Operating Temperature	-10°C
	Maximum Operating Temperature	55°C
	Maximum Voltage	690V ac/dc
	Battery Life	150h
	Standards/Approvals	IEC 610102033, IEC 610101, IEC 61010031
	Length	52mm
	Height	180mm
	Hazardous Area Certification	No
	Width	45 mm
	Safety Category Voltage	600V
	Safety Category Level	CAT III

	Select all
	Brand Chauvin Arnoux
	Product Type Voltage Indicator
	Continuity Check Yes
	Display Type LCD
	RCD Trip Test Yes
	IP Rating IP54
	Battery Type AAA, LR3
	Power Source Battery
	Weight 200g
	Minimum Operating Temperature -10°C
	Maximum Operating Temperature 55°C
	Maximum Voltage 690V ac/dc
	Battery Life 150h
	Standards/Approvals IEC 610102033, IEC 610101, IEC 61010031
	Length 52mm
	Height 180mm
	Hazardous Area Certification No
	Width 45 mm
	Safety Category Voltage 600V
	Safety Category Level CAT III

RoHS Status: Exempt

Chauvin Arnoux Voltage and Continuity Tester C.A 745N

The C.A 745N voltage and continuity tester can test AC and DC voltage up to 690 V, with automatic AC or DC detection. It displays the resistance value on 3 thresholds and also offers audible continuity testing. The C.A 745N can be used for single-pole phase testing, there is no risk of tripping high-sensitivity RCDs when performing a phase/earth test.;The tester is equipped with an LCD screen to display the different thresholds in bargraph form. The test probes are removable and easy to replace. There is an integral compartment built into the instrument to store the probes.

Features and Benefits

• Compact;• Easy to use;• Ergonomic design for comfortable handling;• Battery status check;• Single-pole phase test;• AC and DC voltage test (7 thresholds) with automatic AC or DC detection;• Resistance (3 thresholds) with audible and visual alarm if a voltage is present;• Audible continuity;• 600 V CAT III;• Automatic recognition of AC and DC voltage;• Removable test probes

Voltage Level Indicators

A range of voltage testers each available in versions suitable for electronic or electrical applications.

Supplied with

C.A 745N tester, 1 set of black/red extra-fine CAT III / CAT IV test probes, 2 x 1.5 V AAA / LR3 alkaline batteries and 1 user manual in 5 languages
