STMicroelectronics Panel Mount, 3-pin, TRIAC, 700V, Gate Trigger 1.5V 700V
- RS Stock No.:
- 102-3532
- Mfr. Part No.:
- BTA40-700B
- Brand:
- STMicroelectronics
Bulk discount available
Subtotal (1 bag of 25 units)*
£230.625
(exc. VAT)
£276.75
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit | Per Bag* |
|---|---|---|
| 25 - 25 | £9.225 | £230.63 |
| 50 - 75 | £8.764 | £219.10 |
| 100 - 225 | £8.017 | £200.43 |
| 250 - 475 | £7.648 | £191.20 |
| 500 + | £7.048 | £176.20 |
*price indicative
- RS Stock No.:
- 102-3532
- Mfr. Part No.:
- BTA40-700B
- Brand:
- STMicroelectronics
Specifications
Technical Reference
Legislation and Compliance
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | STMicroelectronics | |
| Rated Average On-State Current | 40A | |
| Mounting Type | Panel Mount | |
| Package Type | RD-91 | |
| Maximum Gate Trigger Current | 100mA | |
| Repetitive Peak Reverse Voltage | 700V | |
| Surge Current Rating | 315A | |
| Pin Count | 3 | |
| Maximum Gate Trigger Voltage | 1.5V | |
| Repetitive Peak Forward Blocking Voltage | 700V | |
| Maximum Holding Current | 80mA | |
| Dimensions | 40 x 27 x 14mm | |
| Length | 40mm | |
| Width | 27mm | |
| Height | 14mm | |
| Minimum Operating Temperature | -40 °C | |
| Maximum Operating Temperature | +125 °C | |
| Repetitive Peak Off-State Current | 0.01mA | |
| Peak On-State Voltage | 1.8V | |
| Select all | ||
|---|---|---|
Brand STMicroelectronics | ||
Rated Average On-State Current 40A | ||
Mounting Type Panel Mount | ||
Package Type RD-91 | ||
Maximum Gate Trigger Current 100mA | ||
Repetitive Peak Reverse Voltage 700V | ||
Surge Current Rating 315A | ||
Pin Count 3 | ||
Maximum Gate Trigger Voltage 1.5V | ||
Repetitive Peak Forward Blocking Voltage 700V | ||
Maximum Holding Current 80mA | ||
Dimensions 40 x 27 x 14mm | ||
Length 40mm | ||
Width 27mm | ||
Height 14mm | ||
Minimum Operating Temperature -40 °C | ||
Maximum Operating Temperature +125 °C | ||
Repetitive Peak Off-State Current 0.01mA | ||
Peak On-State Voltage 1.8V | ||
