TE Connectivity Toggle Switch, Panel Mount, On-On, 3PDT, Solder Terminal

View all Toggle Switches
Currently unavailable
We don't know if this item will be back in stock, RS intend to remove it from our range soon.

Alternative

This product is not currently available. Here is our alternative recommendation.

presentation
TE Connectivity Toggle Switch, Panel Mount, On-On, 3PDT, Solder Terminal, 125V
RS Stock No.
745-5716

Each

£14.20

(exc. VAT)

£17.04

(inc. VAT)

RS Stock No.:
317-190
Mfr. Part No.:
F3TDO9
Brand:
TE Connectivity
Find similar products by selecting one or more attributes.
Select all

Brand

TE Connectivity

Contact Configuration

3PDT

Switch Operation

On-On

Contact Current Rating

6 A @ 250 V ac

Mounting Type

Panel Mount

Terminal Type

Solder

Actuator Length

10.5mm

Contact Resistance

0.01Ω

Contact Material

Fine Silver

Maximum Operating Temperature

+80°C

Mechanical Life

100000Operations

Operating Temperature Range

-20 → +80°C

Minimum Operating Temperature

-20°C

Toggle Switches, Min, Professional


Slow make-and-break action
Chrome-plated lever
Solder bucket terminals
A waterproof cover stock no. 321-212 is available (see accessories)
Silver contacts apart from stock nos. 317-077 317-106 317-099 317-112 317-128 and 317-083 which have gold contacts
0.4VA max load
Glass Filled Polyester case

Note

Care should be taken when soldering not to overheat the switch assembly
For biased switches '(on)' refers to momentary 'on' position

Approvals

CSA

Approvals

CSA
