OPTIBELT 250 S8M 480 Timing Belt, 60 Teeth, 480mm Length, 25mm Width
- RS Stock No.:
- 217-1293
- Mfr. Part No.:
- 250 S8M 480
- Brand:
- OPTIBELT
Bulk discount available
Subtotal (1 unit)*
£25.16
(exc. VAT)
£30.19
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £25.16 |
| 5 - 9 | £24.68 |
| 10 - 24 | £24.16 |
| 25 + | £23.68 |
*price indicative
- RS Stock No.:
- 217-1293
- Mfr. Part No.:
- 250 S8M 480
- Brand:
- OPTIBELT
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | OPTIBELT | |
| Length | 480mm | |
| Width | 25mm | |
| Pitch | 8mm | |
| Number of Teeth | 60 | |
| Profile | S8M | |
| Material | Rubber | |
| Series | STD | |
| Tooth Height | 3.2mm | |
| Minimum Operating Temperature | -30°C | |
| Maximum Operating Temperature | +100°C | |
Select all | ||
|---|---|---|
Brand OPTIBELT | ||
Length 480mm | ||
Width 25mm | ||
Pitch 8mm | ||
Number of Teeth 60 | ||
Profile S8M | ||
Material Rubber | ||
Series STD | ||
Tooth Height 3.2mm | ||
Minimum Operating Temperature -30°C | ||
Maximum Operating Temperature +100°C | ||
The OPTIBELT STD timing belts have curvilinear, particularly shear-resistant teeth. The timing belt is made from chloroprene, with glass-fibre tension cord. The timing belt tooth geometry combined with the belt structure leads to even load distribution and optimised engagement of the timing belt pulleys.
Low noise development
Maintenance-free
High performance
Temperature range from -30°C to +100°C
Maintenance-free
High performance
Temperature range from -30°C to +100°C
