RS PRO Type Type J Thermocouple 4 mm Length, 4 mm Diameter, -40 °C → 750 °C Max
- RS Stock No.:
- 334-2644
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 unit)*
£30.43
(exc. VAT)
£36.52
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 19 unit(s) shipping from 01 June 2026
- Plus 6 unit(s) shipping from 01 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £30.43 |
| 5 - 9 | £29.49 |
| 10 + | £28.24 |
*price indicative
- RS Stock No.:
- 334-2644
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Thermocouple Type | Type J | |
| Product Type | Thermocouple | |
| Probe Diameter | 4mm | |
| Probe Length | 4mm | |
| Probe Material | Stainless Steel | |
| Maximum Temperature Sensed | 750°C | |
| Terminal Type | Connector | |
| Cable Length | 2m | |
| Standards/Approvals | RoHS Compliant | |
| Response Time | 0.7s | |
| Minimum Temperature Sensed | -40°C | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Thermocouple Type Type J | ||
Product Type Thermocouple | ||
Probe Diameter 4mm | ||
Probe Length 4mm | ||
Probe Material Stainless Steel | ||
Maximum Temperature Sensed 750°C | ||
Terminal Type Connector | ||
Cable Length 2m | ||
Standards/Approvals RoHS Compliant | ||
Response Time 0.7s | ||
Minimum Temperature Sensed -40°C | ||
- COO (Country of Origin):
- FR
Bayonet type J thermocouple probe
2-wire bayonet type J thermocouple.
Bayonet at 45% to the cable outlet.
Two-conductor cable outlet glass silk and steel braid insulated.
