Bulk discount available
Subtotal (1 pack of 5 units)*
£27.28
(exc. VAT)
£32.74
(inc. VAT)
Stock information currently inaccessible - Please check back later
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 - 4 | £27.28 | £5.456 |
| 5 - 24 | £23.13 | £4.626 |
| 25 - 49 | £21.63 | £4.326 |
| 50 - 99 | £19.86 | £3.972 |
| 100 + | £17.27 | £3.454 |
*price indicative
- RS Stock No.:
- 521-2955
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Product Type | British Standard Fuse | |
| Fuse Type | HRC | |
| Fuse Size | F1 | |
| Standards/Approvals | No | |
| Application Category | gG | |
| Tag Width | 12.7mm | |
| Tag Type | Blade | |
| Overall Length | 58.5mm | |
| Series | NSD | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Product Type British Standard Fuse | ||
Fuse Type HRC | ||
Fuse Size F1 | ||
Standards/Approvals No | ||
Application Category gG | ||
Tag Width 12.7mm | ||
Tag Type Blade | ||
Overall Length 58.5mm | ||
Series NSD | ||
RoHS Status: Exempt
Eaton NSD Series British Standard Fuse, 32A Current Rating, 550V AC Voltage Rating - NSD32RS
This fuse is designed for industrial applications, offering effective protection for power distribution and cable systems. With a current rating of 32A and a voltage rating of 550V AC, it features a blade-type design and an overall length of 58.5mm. The fuse dimensions are 13.8 x 58.5 mm, ensuring compatibility with industry standards.
Features & Benefits
• Provides good peak let-through current limitation
• Maintains a selective coordination ratio of 1:1:6
• Suitable for RoHS-compliant requirements
• Supports both gG and gM utilisation categories
• Designed with offset blade tags for easy installation
Applications
• Used for power distribution in electrical installations
• Utilised for cable protection in industrial settings
• Compatible with Sefeloc 32NNS and Safeclip SC32 fuse holders
• Ideal for general industrial requiring reliable protection
What is the breaking capacity of this fuse?
The fuse has a breaking capacity of 80kA, ensuring efficient trip protection in case of overloads or short circuits.
How does the fuse maintain operational safety in high current conditions?
It features a high rupture capacity that limits the peak current during a fault, effectively protecting circuits and equipment.
What types of fuse holders are suitable for this fuse?
It is compatible with the Sefeloc 32NNS range and the Safeclip SC32 range, making it versatile for various installations.
What is the significance of the gG utilisation category?
The gG designation indicates that the fuse is designed for general-purpose applications, providing effective protection against overloads and short circuits.
How does the selective coordination ratio benefit system design?
The selective coordination ratio of 1:1:6 allows for precise coordination between fuses in the same circuit, minimising system downtime during faults.
