Infineon Switching Diode, Single, 8 A, 2-Pin 650 V PG-TO-220 IDP08E65D2XKSA1

View all Switching Diodes
Bulk discount available

Subtotal (1 pack of 5 units)*

£9.80

(exc. VAT)

£11.75

(inc. VAT)

Add to Basket
Select or type quantity
Orders below £50.00 (exc. VAT) cost £6.95.
Temporarily out of stock
  • Shipping from 25 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
5 - 45£1.96£9.80
50 - 120£1.862£9.31
125 - 245£1.784£8.92
250 - 495£1.706£8.53
500 +£1.37£6.85

*price indicative

Packaging Options:
RS Stock No.:
259-1518
Mfr. Part No.:
IDP08E65D2XKSA1
Brand:
Infineon
Find similar products by selecting one or more attributes.
Select all

Brand

Infineon

Product Type

Switching Diode

Maximum Forward Current If

8A

Diode Configuration

Single

Sub Type

Diode & Rectifiers

Mount Type

Through Hole

Package Type

PG-TO-220

Pin Count

2

Peak Reverse Recovery Time trr

23ns

Minimum Operating Temperature

-40°C

Maximum Power Dissipation Pd

56W

Peak Non-Repetitive Forward Surge Current Ifsm

60A

Maximum Peak Reverse Repetitive Voltage Vrrm

650V

Maximum Forward Voltage Vf

1.6V

Maximum Operating Temperature

175°C

Standards/Approvals

JEDEC

Series

IDP08E65D2

Automotive Standard

No

The Infineon rapid switching emitter controlled diode. It is qualified according to JEDEC for target applications and junction operating temperature is 175°C.

Fast recovery

Soft switching

Low reverse recovery charge

Easy paralleling

Pb-free lead plating RoHS compliant
