Infineon Switching Diode, Single, 15 A, 2-Pin 650 V TO-220 IDP15E65D1XKSA1
- RS Stock No.:
- 259-1521
- Mfr. Part No.:
- IDP15E65D1XKSA1
- Brand:
- Infineon
Bulk discount available
Subtotal (1 pack of 5 units)*
£4.76
(exc. VAT)
£5.71
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 400 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 5 - 45 | £0.952 | £4.76 |
| 50 - 120 | £0.848 | £4.24 |
| 125 - 245 | £0.80 | £4.00 |
| 250 - 495 | £0.742 | £3.71 |
| 500 + | £0.686 | £3.43 |
*price indicative
- RS Stock No.:
- 259-1521
- Mfr. Part No.:
- IDP15E65D1XKSA1
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Maximum Forward Current If | 15A | |
| Product Type | Switching Diode | |
| Diode Configuration | Single | |
| Sub Type | Diode & Rectifiers | |
| Mount Type | Through Hole | |
| Package Type | TO-220 | |
| Pin Count | 2 | |
| Maximum Power Dissipation Pd | 92W | |
| Peak Non-Repetitive Forward Surge Current Ifsm | 120A | |
| Minimum Operating Temperature | -40°C | |
| Maximum Forward Voltage Vf | 1.7V | |
| Maximum Peak Reverse Repetitive Voltage Vrrm | 650V | |
| Peak Reverse Recovery Time trr | 71ns | |
| Maximum Operating Temperature | 175°C | |
| Series | Rapid1 | |
| Standards/Approvals | RoHS | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Maximum Forward Current If 15A | ||
Product Type Switching Diode | ||
Diode Configuration Single | ||
Sub Type Diode & Rectifiers | ||
Mount Type Through Hole | ||
Package Type TO-220 | ||
Pin Count 2 | ||
Maximum Power Dissipation Pd 92W | ||
Peak Non-Repetitive Forward Surge Current Ifsm 120A | ||
Minimum Operating Temperature -40°C | ||
Maximum Forward Voltage Vf 1.7V | ||
Maximum Peak Reverse Repetitive Voltage Vrrm 650V | ||
Peak Reverse Recovery Time trr 71ns | ||
Maximum Operating Temperature 175°C | ||
Series Rapid1 | ||
Standards/Approvals RoHS | ||
Automotive Standard No | ||
The Infineon emitter control diode, this is switch mode power supply and it is free wheeling diodes in inverters and motor drives.
AC/DC converters
Softness factor >1
Ultra fast recovery
Low forward voltage (VF)
