KOA SG73P 3.3 Ω, 0603 Thick Film Surface Mount Resistor ±1 % 0.33 W - SG73P1JTTD3R30F

Bulk discount available

View bulk pricing options

Subtotal (1 tape of 100 units)*

£4.50

(exc. VAT)

£5.40

(inc. VAT)

In Stock

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

*price indicative

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	KOA
	Product Type	Surface Mount Resistor
	Resistance	3.3Ω
	Technology	Thick Film
	Resistor Type	Anti-Surge
	Package/Case	0603
	Tolerance	±1 %
	Packaging	Pitch Punch Paper
	Power Rating	0.33W
	Voltage	150V
	Automotive Standard	AEC-Q200
	Minimum Operating Temperature	-55°C
	Series	SG73P
	Maximum Operating Temperature	155°C
	Height	0.45mm
	Length	1.6mm
	Termination Style	Solder
	Standards/Approvals	EIAJ RC-2133A, IEC 60115-8, JIS C 5201-8, RoHS
	Width	0.8mm

	Select all
	Brand KOA
	Product Type Surface Mount Resistor
	Resistance 3.3Ω
	Technology Thick Film
	Resistor Type Anti-Surge
	Package/Case 0603
	Tolerance ±1 %
	Packaging Pitch Punch Paper
	Power Rating 0.33W
	Voltage 150V
	Automotive Standard AEC-Q200
	Minimum Operating Temperature -55°C
	Series SG73P
	Maximum Operating Temperature 155°C
	Height 0.45mm
	Length 1.6mm
	Termination Style Solder
	Standards/Approvals EIAJ RC-2133A, IEC 60115-8, JIS C 5201-8, RoHS
	Width 0.8mm

The KOA SG73P series thick film chip resistor. It has a fixed resistance of 3.3 ohm. It is used in circuits to catch inductive lighting surge.

Suitable for both reflow and flow soldering

Superior to RK73 series chip resistors in pulse withstanding voltage and high power

AEC-Q200 qualified
