Bourns, CWF2414, 2414 Shielded Power Inductor with a Ferrite Core, 22 μH ±10 % 340 A Idc Q:15

View all Surface Mount Inductors
Bulk discount available

Subtotal (1 tape of 10 units)*

£0.95

(exc. VAT)

£1.14

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 1,440 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units
Per unit
Per Tape*
10 - 40£0.095£0.95
50 - 90£0.088£0.88
100 - 490£0.073£0.73
500 - 990£0.055£0.55
1000 +£0.043£0.43

*price indicative

Packaging Options:
RS Stock No.:
247-5893
Distrelec Article No.:
304-40-379
Mfr. Part No.:
CWF2414-220K
Brand:
Bourns
Find similar products by selecting one or more attributes.
Select all

Brand

Bourns

Product Type

Power Inductor

Inductance

22μH

Maximum DC Current

340A

Package/Case

2414

Packaging

Tape & Reel

Automotive Standard

No

Shielding

Yes

Pin Count

2

Maximum DC Resistance

1.76Ω

Minimum Operating Temperature

-40°C

Inductance Tolerance

±10 %

Series

CWF2414

Maximum Operating Temperature

125°C

Termination Style

Surface Mount

Depth

1.4mm

Height

1.3mm

Core Material

Ferrite

Standards/Approvals

RoHS

Maximum Self Resonant Frequency

20MHz

Moulded

No

Inductor Construction

Wirewound

Minimum Quality Factor

15

COO (Country of Origin):
TW
The Bourns CWF2414 series chip Inductor feature wire-wound construction on a ferrite core that offers high inductance and low DC Resistance (DCR). It has miniature size and 22 μH inductance with 0.34 A rated current.

High self-resonant frequency

High Q value

Operating temperature is -40 °C to 125 °C

Halogen free
