TDK, VLS-EX, 6045 Shielded Wire-wound SMD Inductor with a Ferrite Core Core, 330 μH 0.2% Shielded 500mA Idc
- RS Stock No.:
- 213-8207
- Mfr. Part No.:
- VLS6045EX-331M
- Brand:
- TDK
Subtotal (1 reel of 1500 units)*
£204.00
(exc. VAT)
£244.50
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 16 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 1500 + | £0.136 | £204.00 |
*price indicative
- RS Stock No.:
- 213-8207
- Mfr. Part No.:
- VLS6045EX-331M
- Brand:
- TDK
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TDK | |
| Inductance | 330 μH | |
| Maximum DC Current | 500mA | |
| Package/Case | 6045 | |
| Length | 6mm | |
| Automotive Standard | AEC-Q200 | |
| Depth | 6mm | |
| Height | 4.5mm | |
| Dimensions | 6 x 6 x 4.5mm | |
| Shielded | Yes | |
| Tolerance | 0.2% | |
| Maximum DC Resistance | 1.872Ω | |
| Series | VLS-EX | |
| Core Material | Ferrite Core | |
| Minimum Operating Temperature | -40°C | |
| Inductor Construction | Shielded | |
| Maximum Operating Temperature | +105°C | |
| Select all | ||
|---|---|---|
Brand TDK | ||
Inductance 330 μH | ||
Maximum DC Current 500mA | ||
Package/Case 6045 | ||
Length 6mm | ||
Automotive Standard AEC-Q200 | ||
Depth 6mm | ||
Height 4.5mm | ||
Dimensions 6 x 6 x 4.5mm | ||
Shielded Yes | ||
Tolerance 0.2% | ||
Maximum DC Resistance 1.872Ω | ||
Series VLS-EX | ||
Core Material Ferrite Core | ||
Minimum Operating Temperature -40°C | ||
Inductor Construction Shielded | ||
Maximum Operating Temperature +105°C | ||
- COO (Country of Origin):
- KR
The TDK VLS-EX series Ferrite core Magnetic Shield Wire Wound, 330uH SMD inductor.
Magnetic shield type wound inductor for power circuits.
High magnetic shield construction achieved by a ferrite magnetic material and compatible with high-density mounting.
Larger current and lower Rdc were achieved by optimizing the ferrite core figure.
High magnetic shield construction achieved by a ferrite magnetic material and compatible with high-density mounting.
Larger current and lower Rdc were achieved by optimizing the ferrite core figure.
