Wurth, WE-LQSH, 4020 Shielded Wire-wound SMD Inductor 6.8 μH ±20% Wire-Wound 1.9A Idc

View all Surface Mount Inductors

Subtotal (1 reel of 3000 units)*

£1,032.00

(exc. VAT)

£1,239.00

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 09 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Reel*
3000 +£0.344£1,032.00

*price indicative

RS Stock No.:
135-4590
Mfr. Part No.:
74405042068
Brand:
Wurth Elektronik
Find similar products by selecting one or more attributes.
Select all

Brand

Wurth Elektronik

Inductance

6.8 μH

Maximum DC Current

1.9A

Package/Case

4020

Length

4mm

Depth

3.7mm

Height

2mm

Dimensions

4 x 3.7 x 2mm

Shielded

Yes

Tolerance

±20%

Maximum DC Resistance

156mΩ

Series

WE-LQSH

Maximum Self Resonant Frequency

19MHz

Inductor Construction

Wire-Wound

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

+125°C

COO (Country of Origin):
CN

WE-LQSH Series SMD Semi-Shielded High Shielded High Saturation Power Inductors


Wurth WE-LQSH SMD Semi-Shielded Power Inductors are compact semi-shielded power inductors with an iron core for applications with high DC output current. These inductors have a soft saturation current behavior and a magnetic adhesive epoxy around the inductor core that reduces disturbing noise and magnetic stray field. The powder core can be loaded with 70% more saturation current than other semi-shielded power inductors.25V maximum peak voltage, operating temperature -40 ºC to +125 ºC

Applications


Integrated DC-DC converters with high ripple currents
Portable devices (smartphones, digital cameras, tablets)
Switching controllers requiring high efficiency
Embedded laptops and PCs
