Panasonic, M Series, 6 x 6.5 x 3 mm Shielded Wire-wound SMD Inductor with a Magnetic Iron Alloy Core, 680 nH ±20%
- RS Stock No.:
- 548-913
- Mfr. Part No.:
- ETQP3MR68YFN
- Brand:
- Panasonic
Save 63% when you buy 500 units
Subtotal (1 pack of 5 units)*
£4.49
(exc. VAT)
£5.39
(inc. VAT)
Stock information currently inaccessible
Units | Per unit | Per Pack* |
---|---|---|
5 - 45 | £0.898 | £4.49 |
50 - 245 | £0.556 | £2.78 |
250 - 495 | £0.336 | £1.68 |
500 + | £0.328 | £1.64 |
*price indicative
- RS Stock No.:
- 548-913
- Mfr. Part No.:
- ETQP3MR68YFN
- Brand:
- Panasonic
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Panasonic | |
Inductance | 680 nH | |
Maximum DC Current | 12A | |
Package/Case | 6 x 6.5 x 3 mm | |
Length | 6mm | |
Depth | 3mm | |
Automotive Standard | AEC-Q200 | |
Shielded | Yes | |
Tolerance | ±20% | |
Series | M Series | |
Core Material | Magnetic Iron Alloy | |
Inductor Construction | Shielded | |
Select all | ||
---|---|---|
Brand Panasonic | ||
Inductance 680 nH | ||
Maximum DC Current 12A | ||
Package/Case 6 x 6.5 x 3 mm | ||
Length 6mm | ||
Depth 3mm | ||
Automotive Standard AEC-Q200 | ||
Shielded Yes | ||
Tolerance ±20% | ||
Series M Series | ||
Core Material Magnetic Iron Alloy | ||
Inductor Construction Shielded | ||
- COO (Country of Origin):
- JP
The Panasonic Power inductors choke coil automotive grade with high heat resistance support operation up to 150 degrees Celsius including self heating and allow short term use up to 180 degrees Celsius depending on conditions. They offer high reliability with strong vibration resistance due to a newly developed integral structure suitable for demanding automotive applications. These inductors provide high bias current with excellent inductance stability using ferrous alloy magnetic material and maintain stable performance across a wide temperature range.
Shielded construction
AEC-Q200 compliant
RoHS compliant
AEC-Q200 compliant
RoHS compliant
