Eaton 1 F Supercapacitor -10 to 30 % Tolerance, Supercap HV 2.7V dc, Through Hole
- RS Stock No.:
- 169-9456
- Mfr. Part No.:
- HV0810-2R7105-R
- Brand:
- Eaton
Subtotal (1 bag of 100 units)*
£61.10
(exc. VAT)
£73.30
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 400 unit(s) shipping from 25 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 100 + | £0.611 | £61.10 |
*price indicative
- RS Stock No.:
- 169-9456
- Mfr. Part No.:
- HV0810-2R7105-R
- Brand:
- Eaton
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Eaton | |
| Capacitance | 1F | |
| Product Type | Supercapacitor | |
| Voltage | 2.7V dc | |
| Mount Type | Through Hole | |
| Packaging | Bag | |
| Diameter | 8.5mm | |
| Automotive Standard | No | |
| Lead Diameter | 0.5mm | |
| Polarity | Positive | |
| Terminal Type | Solder | |
| Lead Pitch | 3.5mm | |
| Leakage Current | 10μA | |
| Pin Count | 2 | |
| Minimum Operating Temperature | -40°C | |
| Equivalent Series Resistance ESR | 200mΩ | |
| Lifetime | 1000 h | |
| Maximum Operating Temperature | 65°C | |
| Depth | 13.5mm | |
| Series | Supercap HV | |
| Standards/Approvals | UL, RoHS | |
| Height | 13.5mm | |
| Tolerance | -10 to 30 % | |
| Package/Case | Cylindrical | |
| Capacitor Family | Electric Double Layer | |
| Select all | ||
|---|---|---|
Brand Eaton | ||
Capacitance 1F | ||
Product Type Supercapacitor | ||
Voltage 2.7V dc | ||
Mount Type Through Hole | ||
Packaging Bag | ||
Diameter 8.5mm | ||
Automotive Standard No | ||
Lead Diameter 0.5mm | ||
Polarity Positive | ||
Terminal Type Solder | ||
Lead Pitch 3.5mm | ||
Leakage Current 10μA | ||
Pin Count 2 | ||
Minimum Operating Temperature -40°C | ||
Equivalent Series Resistance ESR 200mΩ | ||
Lifetime 1000 h | ||
Maximum Operating Temperature 65°C | ||
Depth 13.5mm | ||
Series Supercap HV | ||
Standards/Approvals UL, RoHS | ||
Height 13.5mm | ||
Tolerance -10 to 30 % | ||
Package/Case Cylindrical | ||
Capacitor Family Electric Double Layer | ||
HV series (PowerStor) Super Capacitors
Unique, ultra-high capacitance devices utilizing electrochemical double layer capacitor (EDLC) construction combined with new, high performance materials
Ultra low ESR for high power density
Large capacitance for high energy density
Aluminium (EDLC) Super Capacitors
Note
Eaton formerly known as Bussmann
