RS PRO Steel 60 Teeth Spur Gear, 1.5 Module, 15mm Bore Diam, 90mm Pitch Diam, 50mm Hub Diam

View all Spur Gears
Bulk discount available

Subtotal (1 unit)*

£67.21

(exc. VAT)

£80.65

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 1 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 4£67.21
5 - 9£65.86
10 - 24£64.53
25 +£63.18

*price indicative

RS Stock No.:
521-6525
Brand:
RS PRO
Find similar products by selecting one or more attributes.
Select all

Brand

RS PRO

Module

1.5

Number of Teeth

60

Material

Steel

Bore Diameter

15mm

Pitch Diameter

90mm

Hub Diameter

50mm

Face Width

15mm

RoHS Status: Exempt

COO (Country of Origin):
CN

RS PRO Steel Spur Gears


Use these steel spur gears from RS PRO to get your industrial equipment moving. Our extensive range of spur gears is selected for their high-quality, ease of use and performance while ensuring the correct power, torque multiplication, and speed reduction. To obtain your ideal solution, browse the range using the improved filters to locate the module to suit your application.

Also known as


  • Straight gears

  • Straight-cut gears

  • Spur wheels

  • Spur gearing

Features and Benefits


  • Steel EN8 (080M40/080M46) or equivalent

  • Range of gear ratios

  • Ideally used for speed reduction or increase, torque multiplication, resolution and accuracy in positioning systems.

  • 20° pressure angle

  • Metric

Applications


  • Machine Tools

  • Transmissions

  • Speed Reduction

Note

SSN10/10B and SSN10/12B are hobbed type pinions with cutter runout after the 5 mm gear face width.

Standards

DIN Standard - DIN 867, DIN 3962, DIN 3963, Grade / Quality 9 or equivalent
