Igus 45 Teeth Spur Gear, 3 Module, 16 mm Bore Diam, 135 mm Pitch Diam, 32 mm Hub Diam
- RS Stock No.:
- 272-5772
- Mfr. Part No.:
- P360GM-ST-300-045-00-160-R
- Brand:
- Igus
Subtotal (1 unit)*
£59.33
(exc. VAT)
£71.20
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 09 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £59.33 |
*price indicative
- RS Stock No.:
- 272-5772
- Mfr. Part No.:
- P360GM-ST-300-045-00-160-R
- Brand:
- Igus
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Igus | |
| Product Type | Spur Gear | |
| Module | 3 | |
| Number of Teeth | 45 | |
| Bore Size | 16 mm | |
| Pitch Diameter | 135mm | |
| Hub Diameter | 32mm | |
| Face Width | 19mm | |
| Pressure Angle | 20° | |
| Series | P360GM | |
| Standards/Approvals | RoHS | |
| Select all | ||
|---|---|---|
Brand Igus | ||
Product Type Spur Gear | ||
Module 3 | ||
Number of Teeth 45 | ||
Bore Size 16 mm | ||
Pitch Diameter 135mm | ||
Hub Diameter 32mm | ||
Face Width 19mm | ||
Pressure Angle 20° | ||
Series P360GM | ||
Standards/Approvals RoHS | ||
The Igus Spur gear with good tribological specifications provide a positive, constant speed drive to facilitate daily industrial operations. Its maintenance free properties reduce costs for lubrication and maintenance.
Very tough
Resistant to shock loads
