RS PRO Moulded 50 Teeth Spur Gear, 1 Module, 8 mm Bore Diam, 50 mm Pitch Diam, 18 mm Hub Diam
- RS Stock No.:
- 182-7978
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 unit)*
£13.45
(exc. VAT)
£16.14
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 - 4 | £13.45 |
| 5 - 9 | £13.18 |
| 10 - 24 | £12.90 |
| 25 + | £12.65 |
*price indicative
- RS Stock No.:
- 182-7978
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Module | 1 | |
| Product Type | Spur Gear | |
| Number of Teeth | 50 | |
| Material | Moulded | |
| Bore Size | 8 mm | |
| Pitch Diameter | 50mm | |
| Hub Diameter | 18mm | |
| Face Width | 9mm | |
| Pressure Angle | 20° | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Module 1 | ||
Product Type Spur Gear | ||
Number of Teeth 50 | ||
Material Moulded | ||
Bore Size 8 mm | ||
Pitch Diameter 50mm | ||
Hub Diameter 18mm | ||
Face Width 9mm | ||
Pressure Angle 20° | ||
Standards/Approvals No | ||
The RS PRO Metric spur gear has module 1 with bore diameter of 8mm and face width of 9mm.
Number of Teeth: 50
Material: Steel
