RS PRO Moulded 15 Teeth Spur Gear, 1 Module, 4 mm Bore Diam, 15 mm Pitch Diam, 9 mm Hub Diam
- RS Stock No.:
- 182-7964
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 pack of 2 units)*
£12.42
(exc. VAT)
£14.90
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- Plus 14 unit(s) shipping from 04 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 2 - 8 | £6.21 | £12.42 |
| 10 - 18 | £6.085 | £12.17 |
| 20 - 48 | £5.955 | £11.91 |
| 50 + | £5.84 | £11.68 |
*price indicative
- RS Stock No.:
- 182-7964
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Module | 1 | |
| Product Type | Spur Gear | |
| Number of Teeth | 15 | |
| Material | Moulded | |
| Bore Size | 4 mm | |
| Pitch Diameter | 15mm | |
| Hub Diameter | 9mm | |
| Face Width | 9mm | |
| Pressure Angle | 20° | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Module 1 | ||
Product Type Spur Gear | ||
Number of Teeth 15 | ||
Material Moulded | ||
Bore Size 4 mm | ||
Pitch Diameter 15mm | ||
Hub Diameter 9mm | ||
Face Width 9mm | ||
Pressure Angle 20° | ||
Standards/Approvals No | ||
The RS PRO Metric spur gear has module 1 with bore diameter of 4mm and face width of 9mm.
Number of Teeth: 15
Material: Steel
