RS PRO Grey Uninsulated Female Spade Connector, Open barrel, 6.35 x 0.8mm Tab Size, 0.5mm² to 2mm²
- RS Stock No.:
- 270-7601
- Brand:
- RS PRO
Subtotal (1 bag of 1000 units)*
£125.00
(exc. VAT)
£150.00
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 27,000 unit(s) ready to ship
- Plus 999,972,000 unit(s) shipping from 19 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 1000 + | £0.125 | £125.00 |
*price indicative
- RS Stock No.:
- 270-7601
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Type | Open barrel | |
| Spade Connector Type | Flag Terminal | |
| Minimum Wire Size mm² | 0.5mm² | |
| Gender | Female | |
| Maximum Wire Size mm² | 2mm² | |
| Tab Size | 6.35 x 0.8mm | |
| Tab Thickness | 0.8mm | |
| Tab Width | 6.35mm | |
| Insulation | Uninsulated | |
| Minimum Wire Size AWG | 16AWG | |
| Maximum Wire Size AWG | 14AWG | |
| Termination Method | Crimp | |
| Colour | Grey | |
| Contact Material | Brass | |
| Contact Plating | Tin | |
| Wire Size | 0.5 → 2.0 mm², 20 → 14 AWG | |
| Orientation | Angled | |
| Shrouded/Unshrouded | Unshrouded | |
| Overall Length | 16.8mm | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Type Open barrel | ||
Spade Connector Type Flag Terminal | ||
Minimum Wire Size mm² 0.5mm² | ||
Gender Female | ||
Maximum Wire Size mm² 2mm² | ||
Tab Size 6.35 x 0.8mm | ||
Tab Thickness 0.8mm | ||
Tab Width 6.35mm | ||
Insulation Uninsulated | ||
Minimum Wire Size AWG 16AWG | ||
Maximum Wire Size AWG 14AWG | ||
Termination Method Crimp | ||
Colour Grey | ||
Contact Material Brass | ||
Contact Plating Tin | ||
Wire Size 0.5 → 2.0 mm², 20 → 14 AWG | ||
Orientation Angled | ||
Shrouded/Unshrouded Unshrouded | ||
Overall Length 16.8mm | ||
- COO (Country of Origin):
- TW
RS PRO Grey Uninsulated Spade Connector, 6.35 x 0.8 mm Tab Size, 0.5 mm² to 2 mm²
Use this spade connector to join single wires to relays or components, or in any situation where you need to make fast, reliable connections. This spade connector is made to fit 6.35 mm receptacles and its design allows terminals to be connected and disconnected while the bolt is still partially screwed in.
Tin-plated brass contacts provide extra strength and conductivity while making it more resistant to corrosion, oxidation and degradation. Designed for crimp termination, the connector allows you to create mechanically strong solder-free joints using only a pair of pliers. It's a method that is suited for large and small cross-section wires, which can be easily slotted into the component once the other wire has been crimped on the opposite end.
This spade connector is most often found in automotive electronics applications, as well as domestic appliances such as washing machines and dishwashers.
Features and Benefits
- Grey spade connector
- Wire size range of 0.5 mm² to 2.0 mm², 20 AWG to 14 AWG
- Tab size of 0.8 mm x 6.35 mm
- Length of 16.8 mm
- Unshrouded
- Crimp termination method
- Uninsulated
- Tin-plated brass contacts
RS PRO
RS PRO is our own brand range and brings you a wide range of high-quality, great value products offering you more choice. Trusted by engineers all over the world, every part of every RS PRO product has been rigorously tested against demanding industry standards
they’re only given the RS PRO Seal of Approval if we’re confident of their exceptional quality, which means you can be confident too.
Small Pack Size
Per Unit, RS stock no: 488-1336
Large Pack Size
RS stock no: 270-7601
