Molex Blue Insulated Female Spade Connector, Receptacle, 0.81 x 6.35mm Tab Size, 1.3mm² to 2mm²
- RS Stock No.:
- 186-0278
- Mfr. Part No.:
- 19002-0024
- Brand:
- Molex
Subtotal (1 bag of 1000 units)*
£359.23
(exc. VAT)
£431.08
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 2 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Bag(s) | Per Bag | Per unit* |
|---|---|---|
| 1 + | £359.23 | £0.359 |
*price indicative
- RS Stock No.:
- 186-0278
- Mfr. Part No.:
- 19002-0024
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Type | Receptacle | |
| Gender | Female | |
| Minimum Wire Size mm² | 1.3mm² | |
| Maximum Wire Size mm² | 2mm² | |
| Tab Size | 0.81 x 6.35mm | |
| Insulation | Insulated | |
| Maximum Wire Size AWG | 14AWG | |
| Minimum Wire Size AWG | 16AWG | |
| Termination Method | Crimp | |
| Colour | Blue | |
| Contact Material | Brass | |
| Contact Plating | Tin | |
| Insulation Material | Nylon | |
| Overall Length | 22.6mm | |
| Series Number | 19002 | |
Select all | ||
|---|---|---|
Brand Molex | ||
Type Receptacle | ||
Gender Female | ||
Minimum Wire Size mm² 1.3mm² | ||
Maximum Wire Size mm² 2mm² | ||
Tab Size 0.81 x 6.35mm | ||
Insulation Insulated | ||
Maximum Wire Size AWG 14AWG | ||
Minimum Wire Size AWG 16AWG | ||
Termination Method Crimp | ||
Colour Blue | ||
Contact Material Brass | ||
Contact Plating Tin | ||
Insulation Material Nylon | ||
Overall Length 22.6mm | ||
Series Number 19002 | ||
- COO (Country of Origin):
- US
Avikrimp Fully Insulated Quick Disconnect, Female, for 14-16 AWG Wire, Box.
