RS PRO Blue Insulated Female Spade Connector, Double Crimp, 3.9mm Tab Size, 1.5mm² to 2.5mm²
- RS Stock No.:
- 178-8354
- Brand:
- RS PRO
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 178-8354
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Type | Double Crimp | |
| Spade Connector Type | Receptacle | |
| Minimum Wire Size mm² | 1.5mm² | |
| Gender | Female | |
| Maximum Wire Size mm² | 2.5mm² | |
| Tab Size | 3.9mm | |
| Tab Width | 3.9mm | |
| Insulation | Insulated | |
| Maximum Wire Size AWG | 14AWG | |
| Minimum Wire Size AWG | 16AWG | |
| Termination Method | Crimp | |
| Colour | Blue | |
| Contact Material | Brass, Copper | |
| Contact Plating | Tin | |
| Wire Size | 1.5 → 2.5 mm², 16 → 14 AWG | |
| Orientation | Straight | |
| Insulation Material | Nylon | |
| Overall Length | 25.2mm | |
| Shrouded/Unshrouded | Shrouded | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Type Double Crimp | ||
Spade Connector Type Receptacle | ||
Minimum Wire Size mm² 1.5mm² | ||
Gender Female | ||
Maximum Wire Size mm² 2.5mm² | ||
Tab Size 3.9mm | ||
Tab Width 3.9mm | ||
Insulation Insulated | ||
Maximum Wire Size AWG 14AWG | ||
Minimum Wire Size AWG 16AWG | ||
Termination Method Crimp | ||
Colour Blue | ||
Contact Material Brass, Copper | ||
Contact Plating Tin | ||
Wire Size 1.5 → 2.5 mm², 16 → 14 AWG | ||
Orientation Straight | ||
Insulation Material Nylon | ||
Overall Length 25.2mm | ||
Shrouded/Unshrouded Shrouded | ||
- COO (Country of Origin):
- TW
RS PRO NYLON-FULLY INSULATED DOUBLE CRIMP RECEPTACLE DISCONNECTORS
