e2s AB105LDA Series Amber, Blue, Clear, Green, Red, Yellow LED Beacon, 24 V, IP65, Wall Mount, 113dB at 1 Metre
- RS Stock No.:
- 248-4877
- Mfr. Part No.:
- AB105LDADC024AA0A1G/R
- Brand:
- e2s
Subtotal (1 unit)*
£269.61
(exc. VAT)
£323.53
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 + | £269.61 |
*price indicative
- RS Stock No.:
- 248-4877
- Mfr. Part No.:
- AB105LDADC024AA0A1G/R
- Brand:
- e2s
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | e2s | |
Supply Voltage | 24 V | |
Lens Colour | Amber, Blue, Clear, Green, Red, Yellow | |
Mounting Style | Wall Mount | |
Current Type | Vdc | |
Light Effect | Flashing, Rotating, Steady | |
Decibels at 1 Metre | 113dB | |
Series | AB105LDA | |
Bulb Type | LED | |
IP Rating | IP65 | |
Select all | ||
---|---|---|
Brand e2s | ||
Supply Voltage 24 V | ||
Lens Colour Amber, Blue, Clear, Green, Red, Yellow | ||
Mounting Style Wall Mount | ||
Current Type Vdc | ||
Light Effect Flashing, Rotating, Steady | ||
Decibels at 1 Metre 113dB | ||
Series AB105LDA | ||
Bulb Type LED | ||
IP Rating IP65 | ||
- COO (Country of Origin):
- GB
The e2s AB105LDA Alarm horn sounder and LED beacon a compact high output 113dB(A) alarm sounder with a powerful multi-function LED beacon, featuring 64 alarm tone frequencies and 4 remotely activated stages/channels, an alternative second stage beacon mode can be remotely activated via a third wire, with low current consumption and high SPL in a robust fire retardant enclosure.
Automatic synchronisation on multi-sounder system
Synchronised flash rates
Continuously rated
Stainless steel fixings
Unit can be mounted using external lugs or internal fixing positions
Dual M20 x 1.5 mm threaded cable entries
Duplicate pluggable cable terminations Class A
Diode polarized for use in supervised circuits
64 alarm tone frequencies and 4 remotely activated alarm stages
Available with custom tone configurations and frequencies
6 LED beacon modes including rotating and steady functions
DC voltage units feature a second remotely selectable beacon mode stage
Can be mounted in any orientation
Synchronised flash rates
Continuously rated
Stainless steel fixings
Unit can be mounted using external lugs or internal fixing positions
Dual M20 x 1.5 mm threaded cable entries
Duplicate pluggable cable terminations Class A
Diode polarized for use in supervised circuits
64 alarm tone frequencies and 4 remotely activated alarm stages
Available with custom tone configurations and frequencies
6 LED beacon modes including rotating and steady functions
DC voltage units feature a second remotely selectable beacon mode stage
Can be mounted in any orientation
