Celduc XK Series Solid State Relay, 10 A Load, DIN Rail Mount, 36 V dc Load, 30 V dc Control
- RS Stock No.:
- 917-4885
- Mfr. Part No.:
- XKLD31006
- Brand:
- Celduc
14 In stock for delivery within 1 working days
Not available for guaranteed pre 9am/10am delivery
Added
Price Each
£58.68
(exc. VAT)
£70.42
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £58.68 |
| 5 - 9 | £56.34 |
| 10 + | £55.17 |
- RS Stock No.:
- 917-4885
- Mfr. Part No.:
- XKLD31006
- Brand:
- Celduc
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- FR
Product Details
Non-pull-out vertical relays for DIN rail
Non-pull-out vertical relays for DIN Rail
Relays for controlling all types of loads.
These relays feature a high level of immunity to outside interference, a low off-state leakage current and a surge suppressor.
Relays for controlling all types of loads.
These relays feature a high level of immunity to outside interference, a low off-state leakage current and a surge suppressor.
Specifications
Attribute | Value |
|---|---|
| Maximum Load Current | 10 A |
| Mounting Type | DIN Rail |
| Maximum Load Voltage | 36 V dc |
| Minimum Load Voltage | 12 V dc |
| Maximum Control Voltage | 30 V dc |
| Minimum Control Voltage | 10 V dc |
| Switching Type | DC |
| Control Voltage Range | 10 → 30 V dc |
| Range | XK |
| Number of Poles | 1 |
| Terminal Type | PCB Pin |
| Output Device | Bipolar Transistor |
| Relay Type | DC Interface Relay |
| Series | XK |
| Maximum Turn On Time | 1 μs |
| Load Voltage Range | 12 → 36 V dcV |
| Dimensions | 76.4 x 12.2 x 53mm |
| Maximum Operating Temperature | +90°C |
| Minimum Operating Temperature | -25°C |
| Special Features | Control Visualization By LED. |
| Standards Met | CE, EAC |
| Depth | 53mm |
| Length | 12.2mm |
| Off State Leakage Current | 0.1 mA |
| Height | 76.4mm |
