Celduc SP-ST-SL Series Solid State Relay, 2 A Load, PCB Mount, 30 V dc Load, 30 V dc Control
- RS Stock No.:
- 917-4832
- Mfr. Part No.:
- STD03505
- Brand:
- Celduc
Bulk discount available
Subtotal (1 unit)*
£28.66
(exc. VAT)
£34.39
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 37 unit(s) ready to ship from another location
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £28.66 |
| 5 - 9 | £27.52 |
| 10 + | £26.96 |
*price indicative
- RS Stock No.:
- 917-4832
- Mfr. Part No.:
- STD03505
- Brand:
- Celduc
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Celduc | |
| Maximum Load Current | 2 A | |
| Mounting Type | PCB Mount | |
| Maximum Load Voltage | 30 V dc | |
| Minimum Load Voltage | 0 V dc | |
| Maximum Control Voltage | 30 V dc | |
| Minimum Control Voltage | 12 V dc | |
| Switching Type | DC | |
| Control Voltage Range | 12 → 30 V dc | |
| Range | ST | |
| Number of Poles | 1 | |
| Contact Configuration | SPST | |
| Terminal Type | PCB Pin | |
| Output Device | Bipolar Transistor | |
| Relay Type | DC | |
| Series | SP-ST-SL | |
| Maximum Turn On Time | 0.05ms | |
| Load Voltage Range | 0 → 30V dc | |
| Dimensions | 29.2 x 13 x 15.8mm | |
| Depth | 13mm | |
| Maximum Operating Temperature | +100°C | |
| Height | 15.8mm | |
| Special Features | Sustain high Inrush current . | |
| Standards Met | cULus Recognized | |
| Operating Temperature Range | -40 → +100°C | |
| Minimum Operating Temperature | -40°C | |
| Length | 29.2mm | |
Select all | ||
|---|---|---|
Brand Celduc | ||
Maximum Load Current 2 A | ||
Mounting Type PCB Mount | ||
Maximum Load Voltage 30 V dc | ||
Minimum Load Voltage 0 V dc | ||
Maximum Control Voltage 30 V dc | ||
Minimum Control Voltage 12 V dc | ||
Switching Type DC | ||
Control Voltage Range 12 → 30 V dc | ||
Range ST | ||
Number of Poles 1 | ||
Contact Configuration SPST | ||
Terminal Type PCB Pin | ||
Output Device Bipolar Transistor | ||
Relay Type DC | ||
Series SP-ST-SL | ||
Maximum Turn On Time 0.05ms | ||
Load Voltage Range 0 → 30V dc | ||
Dimensions 29.2 x 13 x 15.8mm | ||
Depth 13mm | ||
Maximum Operating Temperature +100°C | ||
Height 15.8mm | ||
Special Features Sustain high Inrush current . | ||
Standards Met cULus Recognized | ||
Operating Temperature Range -40 → +100°C | ||
Minimum Operating Temperature -40°C | ||
Length 29.2mm | ||
- COO (Country of Origin):
- FR
SLA and SLD series miniature solid state relays for 5 mm support
Pin compatibility with electromechanical relays
Integral RC network (SLA series)
Built-in surge clipper (SLD series)
Relays only 5 mm thick
Integral RC network (SLA series)
Built-in surge clipper (SLD series)
Relays only 5 mm thick
