i-Autoc KSI Series Solid State Relay, 60 A Load, Panel Mount, 280 V ac Load, 32 V dc Control

RS Stock No.:: 903-2968
Mfr. Part No.:: KSI240D60-L
Brand:: i-Autoc

i-Autoc KSI Series Solid State Relay, 60 A Load, Panel Mount, 280 V ac Load, 32 V dc Control

15 In stock - FREE next working day delivery available

Price Each

£25.96

(exc. VAT)

£31.15

(inc. VAT)

Units	Per unit
1 +	£25.96

RS Stock No.:: 903-2968
Mfr. Part No.:: KSI240D60-L
Brand:: i-Autoc

Datasheet

Attribute	Value
Maximum Load Current	60 A
Mounting Type	Panel Mount
Maximum Load Voltage	280 V ac
Minimum Load Voltage	48 V ac
Maximum Control Voltage	32 V dc
Minimum Control Voltage	4 V dc
Switching Type	Zero Cross
Control Voltage Range	4 → 32 V dc
Terminal Type	Screw
Output Device	SCR, Triac
Relay Type	Industrial Single Phase Relay
Series	KSI
Load Voltage Range	48 → 280V ac
Maximum Turn On Time	1ms
Dimensions	58.6 x 45.7 x 26.5mm
Special Features	Internal MOV, Internal RC, LED Indication, Superior Thermal Performance, TVS Protection Circuit as Option
Standards Met	CE, TUV, UL
Minimum Operating Temperature	-30°C
Depth	45.7mm
Height	26.5mm
Off State Leakage Current	5 mA
Length	58.6mm
Operating Temperature Range	-30 → +80°C
Maximum Operating Temperature	+80°C

i-Autoc KSI Series Solid State Relay, 60 A Load, Panel Mount, 280 V ac Load, 32 V dc Control

KSI (068) Series Solid State Relay

I-Autoc KSI (068) Series Single Phase Solid State Relay
