i-Autoc KSI Series Solid State Relay, 60 A Load, Panel Mount, 280 V ac Load, 32 V dc Control
- RS Stock No.:
- 903-2927
- Mfr. Part No.:
- KSI240D60-L(068)
- Brand:
- i-Autoc
6 In stock - FREE next working day delivery available
Added
Price Each
£33.73
(exc. VAT)
£40.48
(inc. VAT)
| Units | Per unit |
| 1 + | £33.73 |
- RS Stock No.:
- 903-2927
- Mfr. Part No.:
- KSI240D60-L(068)
- Brand:
- i-Autoc
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
KSI (068) Series Solid State Relay
The KSI(068) series industrial single phase relay with IP20 touch-safe cover is the most widely used in industryapplication.The relay can be used for resistive, inductive and capacitive loads. The control input voltage is4-32VDC or 90-280VAC, output current rate 25A, 40A, 60A, 80A @ 48-660VAC.
Application for high-low temperature chamber, plastics machinery, incubation machine, oiling machine, HVAC, elevator, lighting, fountain controller.
Application for high-low temperature chamber, plastics machinery, incubation machine, oiling machine, HVAC, elevator, lighting, fountain controller.
IP20 touch safe cover
Zero switching or random-on
Output current 25A, 40A, 60A,80A
Load voltage 48 to 280 V ac, 18 to 440 V ac, 48 to 530 V ac or 48 to 660 V ac
SCR output
Dielectric strength 400 VACrms
Internal RS/MOV and TVS protection
Operating temperature range -30 ℃ to +80 ℃
Zero switching or random-on
Output current 25A, 40A, 60A,80A
Load voltage 48 to 280 V ac, 18 to 440 V ac, 48 to 530 V ac or 48 to 660 V ac
SCR output
Dielectric strength 400 VACrms
Internal RS/MOV and TVS protection
Operating temperature range -30 ℃ to +80 ℃
I-Autoc KSI (068) Series Single Phase Solid State Relay
Approvals
RoHS
Zero Voltage Relays
Note
Temperature can affect current rating; please consult the data sheet for potential derating.
Specifications
Attribute | Value |
|---|---|
| Maximum Load Current | 60 A |
| Mounting Type | Panel Mount |
| Maximum Load Voltage | 280 V ac |
| Minimum Load Voltage | 48 V ac |
| Maximum Control Voltage | 32 V dc |
| Minimum Control Voltage | 4 V dc |
| Switching Type | Zero Cross |
| Control Voltage Range | 4 → 32 V dc |
| Terminal Type | Screw |
| Output Device | SCR, Triac |
| Relay Type | Industrial Single Phase Relay |
| Series | KSI |
| Load Voltage Range | 48 → 280V ac |
| Maximum Turn On Time | 1ms |
| Dimensions | 58.6 x 45.7 x 26.5mm |
| Minimum Operating Temperature | -30°C |
| Off State Leakage Current | 5 mA |
| Length | 58.6mm |
| Operating Temperature Range | -30 → +80°C |
| Standards Met | CE, TUV, UL |
| Height | 26.5mm |
| Depth | 45.7mm |
| Special Features | Internal MOV, Internal RC, LED Indication, Superior Thermal Performance, TVS Protection Circuit as Option |
| Maximum Operating Temperature | +80°C |
