i-Autoc KSJ Series Solid State Relay, 40 A Load, Panel Mount, 100 V dc Load, 32 V dc Control
- RS Stock No.:
- 903-2920
- Mfr. Part No.:
- KSJ100D40-L(068)
- Brand:
- i-Autoc
2 In stock - FREE next working day delivery available
Added
Price Each
£48.90
(exc. VAT)
£58.68
(inc. VAT)
| Units | Per unit |
| 1 + | £48.90 |
- RS Stock No.:
- 903-2920
- Mfr. Part No.:
- KSJ100D40-L(068)
- Brand:
- i-Autoc
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- CN
Product Details
KSJ100 (068) Series Solid State Relay
The KSJ100(068) series is a DC output, panel mounted solid state relay. With a control voltage of 4 to 32 V dc, load voltage of 0-100V dc, output current of 20A,40A or 80A. Opto-isolation between input and output and a dielectric strength of ≥2500VACrms. Applications suitable for DC heating, DC power, DC valve, DC motor, solar energy and many more.
IP20 touch safe cover
Ratings 20 A, 40 A, 80 A @ 100 V dc
4 to 32 V dc control input
Dielectric Strength ≥2500VACrms
Minimum turn on voltage 4 V dc
Minimum turn off voltage 1 V dc
Operating temperature -30℃ to +80℃
Weight 90g
Opto-isolation
Panel mounted
RoHS compliant
Ratings 20 A, 40 A, 80 A @ 100 V dc
4 to 32 V dc control input
Dielectric Strength ≥2500VACrms
Minimum turn on voltage 4 V dc
Minimum turn off voltage 1 V dc
Operating temperature -30℃ to +80℃
Weight 90g
Opto-isolation
Panel mounted
RoHS compliant
KSJ100(068) Series DC Output Solid State Relay
Approvals
RoHS
Zero Voltage Relays
Note
Temperature can affect current rating; please consult the data sheet for potential derating.
Specifications
Attribute | Value |
|---|---|
| Maximum Load Current | 40 A |
| Mounting Type | Panel Mount |
| Maximum Load Voltage | 100 V dc |
| Minimum Load Voltage | 0 V dc |
| Minimum Control Voltage | 4 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Zero |
| Control Voltage Range | 4 → 32 V dc |
| Terminal Type | Screw |
| Output Device | MOSFET |
| Load Voltage Range | 0 → 100V dc |
| Series | KSJ |
| Maximum Turn On Time | 0.1ms |
| Dimensions | 58.6 x 45.7 x 26.5mm |
| Special Features | Dielectric Strength≥2500 Vacrms, KSJ100 Series |
| Standards Met | CE, RoHS Compliant |
| Minimum Operating Temperature | -30°C |
| Maximum Operating Temperature | +80°C |
| Depth | 45.7mm |
| Height | 26.5mm |
| Off State Leakage Current | 0.1 mA |
| Length | 58.6mm |
| Operating Temperature Range | -30 → +80°C |
