Panasonic Solid State Relay, 80 mA Load, PCB Mount, 400 V Load, 1.5 V Control
- RS Stock No.:
- 173-9023
- Mfr. Part No.:
- AQW214S
- Brand:
- Panasonic
50 In stock - FREE next working day delivery available
Added
Price Each (In a Tube of 50)
£3.672
(exc. VAT)
£4.406
(inc. VAT)
| Units | Per unit | Per Tube* |
| 50 + | £3.672 | £183.60 |
| *price indicative | ||
- RS Stock No.:
- 173-9023
- Mfr. Part No.:
- AQW214S
- Brand:
- Panasonic
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- JP
Product Details
AQW Series
Controls low-level analog signals
Low-level off state leakage current of max. 1 μA
Low-level off state leakage current of max. 1 μA
Approvals
UL, C-UL
Specifications
Attribute | Value |
|---|---|
| Maximum Load Current | 80 mA |
| Mounting Type | PCB Mount |
| Maximum Load Voltage | 400 V |
| Maximum Control Voltage | 1.5 V |
| Minimum Load Current | 0.08 A |
| Contact Configuration | DPST |
| Output Device | MOSFET |
| Maximum Turn On Time | 0.5ms |
| Load Voltage Range | 400V |
| Dimensions | 9.37 x 4.4 x 2.1mm |
| Operating Temperature Range | -40 → +85°C |
| Length | 9.4mm |
| Off State Leakage Current | 1 μA |
| Maximum Operating Temperature | +85°C |
| Height | 2.1mm |
| Minimum Operating Temperature | -40°C |
| Depth | 4.4mm |
