Sensata Crydom SMR24-6 Series Solid State Relay, 25 A Load, Panel Mount, 280 Vrms Load, 32 V dc Control
- RS Stock No.:
- 145-0606
- Mfr. Part No.:
- SMR2425-6
- Brand:
- Sensata / Crydom
Subtotal (1 unit)*
£94.78
(exc. VAT)
£113.74
(inc. VAT)
FREE delivery for orders over £50.00
- 10 unit(s) shipping from 29 September 2025
- Plus 20 unit(s) shipping from 28 October 2025
Units | Per unit |
|---|---|
| 1 - 4 | £94.78 |
| 5 - 9 | £90.03 |
| 10 - 24 | £85.30 |
| 25 - 49 | £80.56 |
| 50 + | £75.83 |
*price indicative
- RS Stock No.:
- 145-0606
- Mfr. Part No.:
- SMR2425-6
- Brand:
- Sensata / Crydom
Select all | Attribute | Value |
|---|---|---|
| Brand | Sensata / Crydom | |
| Maximum Load Current | 25 A | |
| Mounting Type | Panel Mount | |
| Maximum Load Voltage | 280 Vrms | |
| Minimum Load Voltage | 60Vrms | |
| Minimum Control Voltage | 8 V dc | |
| Maximum Control Voltage | 32 V dc | |
| Switching Type | Zero Cross | |
| Control Voltage Range | 8 → 32 V dc | |
| Minimum Load Current | 40 A rms | |
| Number of Poles | 1 | |
| Terminal Type | Screw | |
| Relay Type | Solid State Relay | |
| Series | SMR24-6 | |
| Load Voltage Range | 60 → 280Vrms | |
| Maximum Turn On Time | 1/2 cycle | |
| Dimensions | 45.7 x 58.4 x 24.2mm | |
| Height | 24.2mm | |
| Minimum Operating Temperature | -40°C | |
| Special Features | Alarm Output Signal, DC Control, Inverting Or Non-Inverting Input, LED Status Indicators, Normally Open Or Normally Closed Alarm Output | |
| Standards Met | CE | |
| Depth | 58.4mm | |
| Capacitance | 8pF | |
| Maximum Operating Temperature | +80°C | |
| Off State Leakage Current | 10mArms | |
| Length | 45.7mm | |
| Operating Temperature Range | -40 → +80°C | |
Select all | ||
|---|---|---|
Brand Sensata / Crydom | ||
Maximum Load Current 25 A | ||
Mounting Type Panel Mount | ||
Maximum Load Voltage 280 Vrms | ||
Minimum Load Voltage 60Vrms | ||
Minimum Control Voltage 8 V dc | ||
Maximum Control Voltage 32 V dc | ||
Switching Type Zero Cross | ||
Control Voltage Range 8 → 32 V dc | ||
Minimum Load Current 40 A rms | ||
Number of Poles 1 | ||
Terminal Type Screw | ||
Relay Type Solid State Relay | ||
Series SMR24-6 | ||
Load Voltage Range 60 → 280Vrms | ||
Maximum Turn On Time 1/2 cycle | ||
Dimensions 45.7 x 58.4 x 24.2mm | ||
Height 24.2mm | ||
Minimum Operating Temperature -40°C | ||
Special Features Alarm Output Signal, DC Control, Inverting Or Non-Inverting Input, LED Status Indicators, Normally Open Or Normally Closed Alarm Output | ||
Standards Met CE | ||
Depth 58.4mm | ||
Capacitance 8pF | ||
Maximum Operating Temperature +80°C | ||
Off State Leakage Current 10mArms | ||
Length 45.7mm | ||
Operating Temperature Range -40 → +80°C | ||
