EMERSON – ASCO Solenoid Valve 18900011.24/DC, 3 Port, NO M5, 24 V, M5

View all Solenoid Valves

Subtotal (1 unit)*

£59.01

(exc. VAT)

£70.81

(inc. VAT)

Add to Basket
Select or type quantity
Orders below £50.00 (exc. VAT) cost £6.95.
Temporarily out of stock
  • Shipping from 31 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 +£59.01

*price indicative

RS Stock No.:
432-364
Mfr. Part No.:
18900011.24/DC
Brand:
EMERSON ? ASCO
Find similar products by selecting one or more attributes.
Select all

Brand

EMERSON ? ASCO

Supply Voltage

24 V

Product Type

Solenoid Valve

Number of Ports

3

Inlet Port Size

M5

Outlet Port Size

M5

Default Valve Position

NO

Outlet Connection Type

Threaded

Inlet Thread Standard

ISO 228/1

Inlet Connection Type

Threaded

Orifice Diameter

1.2mm

Application

Air, Inert Gas

Series

189

Body Material

Polyamide

Maximum Operating Pressure

10 bar

Outlet Thread Standard

ISO 228/1

Minimum Operating Temperature

-10°C

Maximum Operating Temperature

60°C

Servo Assist

No

Standards/Approvals

UL, ISO 15218 (CNOMO 06-05-80 / NF E 49066,size 30), IEC 335, CSA, EN 60529 (IP65)

Hazardous Area Certification

ATEX Directive 2014/34/EU, UL, CSA

Flow Factor Kv

1.2L/min

Maximum Closing Time

10ms

Maximum Opening Time

5ms

RoHS Status: Exempt

COO (Country of Origin):
FR
The Asco solenoid valve is designed for versatility and reliability in various industrial applications. With its 3-way configuration and compact design, it fits seamlessly into any subbase system, facilitating efficient fluid control. The valve supports both normally closed and normally open operating modes, catering to diverse operational needs. Built with robust materials, it ensures longevity and sustained performance even under pressure. Easy to install and maintain, this solenoid valve promotes efficiency and reliability in pneumatic systems, meeting stringent industry standards.

Offers AC/DC interchangeability without valve disassembly

Constructed with glass-filled PA for enhanced durability

Includes visual indication with M12 connection options

Designed for flexible installation on joinable subbases

Features manual operation capability as an integral standard

Meets all relevant EU directives, ensuring compliance and safety

Provides fast response times for quick operational changes

Utilises NBR seals for effective resistance to wear and tear
