Vishay Single Layer Ceramic Capacitor (SLCC) 400pF 50kV dc ±20% N4700 Dielectric, 715C, Screw Terminal +85°C Max Op.
- RS Stock No.:
- 210-1591
- Mfr. Part No.:
- 715C50KTT40M4
- Brand:
- Vishay
Available to back order for despatch 06/08/2024
Added
Price Each
£45.75
(exc. VAT)
£54.90
(inc. VAT)
| Units | Per unit |
| 1 - 4 | £45.75 |
| 5 - 9 | £43.92 |
| 10 - 24 | £41.18 |
| 25 - 49 | £38.89 |
| 50 + | £36.60 |
- RS Stock No.:
- 210-1591
- Mfr. Part No.:
- 715C50KTT40M4
- Brand:
- Vishay
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
The Vishay high voltage class 1 ceramic single layer AC and DC disc capacitors works with an operational voltage of 50000 V DC. It can be used in high voltage power supplies, CO2 lasers, X-ray equipment, Welding equipment, Industrial applications.
0.2% at 1kHz dissipation factor
Screw terminal mounting
Screw terminal mounting
Specifications
Attribute | Value |
|---|---|
| Capacitance | 400pF |
| Voltage | 50kV dc |
| Mounting Type | Screw Terminal |
| Series | 715C |
| Tolerance | ±20% |
| Dielectric | N4700 |
| Diameter | 32mm |
| Height | 32mm |
| Dimensions | 32 (Dia.) x 32mm |
| Suppression Class | Class I |
| Terminal Type | Screw |
| Minimum Operating Temperature | -30°C |
| Dielectric Material Family | Ceramic |
| Tolerance Plus | +20% |
| Capacitor Family | Single Layer |
| Tolerance Minus | -20% |
| Maximum Operating Temperature | +85°C |
