Vishay Single Layer Ceramic Capacitor (SLCC) 3.3nF 30kV dc -20 → +80% Y5U Dielectric, 715C, Screw Terminal +85°C
- RS Stock No.:
- 210-1574
- Mfr. Part No.:
- 715C30DKD33
- Brand:
- Vishay
Bulk discount available
Subtotal (1 unit)*
£102.02
(exc. VAT)
£122.42
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 6 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 1 | £102.02 |
2 - 4 | £96.92 |
5 - 9 | £89.77 |
10 - 24 | £81.62 |
25 + | £76.51 |
*price indicative
- RS Stock No.:
- 210-1574
- Mfr. Part No.:
- 715C30DKD33
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Vishay | |
Capacitance | 3.3nF | |
Voltage | 30kV dc | |
Mounting Type | Screw Terminal | |
Series | 715C | |
Tolerance | -20 → +80% | |
Dielectric | Y5U | |
Suppression Class | Class II | |
Minimum Operating Temperature | -30°C | |
Dielectric Material Family | Ceramic | |
Capacitor Family | Single Layer | |
Tolerance Minus | -20% | |
Terminal Type | Screw | |
Tolerance Plus | +80% | |
Maximum Operating Temperature | +85°C | |
Select all | ||
---|---|---|
Brand Vishay | ||
Capacitance 3.3nF | ||
Voltage 30kV dc | ||
Mounting Type Screw Terminal | ||
Series 715C | ||
Tolerance -20 → +80% | ||
Dielectric Y5U | ||
Suppression Class Class II | ||
Minimum Operating Temperature -30°C | ||
Dielectric Material Family Ceramic | ||
Capacitor Family Single Layer | ||
Tolerance Minus -20% | ||
Terminal Type Screw | ||
Tolerance Plus +80% | ||
Maximum Operating Temperature +85°C | ||
- COO (Country of Origin):
- DE
The Vishay high voltage class 1 ceramic single layer AC and DC disc capacitors works with an operational voltage of 30000 V DC. It can be used in high voltage power supplies, CO2 lasers, X-ray equipment, Welding equipment, Industrial applications.
0.2% at 1kHz dissipation factor
Screw terminal mounting
Screw terminal mounting
