RS PRO Single Layer Ceramic Capacitor (SLCC) 1nF 2kV dc ±10% LR Dielectric, Through Hole +125°C Max Op. Temp.
- RS Stock No.:
- 180-4818
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 bag of 1000 units)*
£75.00
(exc. VAT)
£90.00
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 1,000 unit(s) ready to ship
- Plus 999,998,000 unit(s) shipping from 13 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 1000 - 2000 | £0.075 | £75.00 |
| 3000 + | £0.066 | £66.00 |
*price indicative
- RS Stock No.:
- 180-4818
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Capacitance | 1nF | |
| Voltage | 2kV dc | |
| Mounting Type | Through Hole | |
| Tolerance | ±10% | |
| Dielectric | LR | |
| Diameter | 10.5mm | |
| Tolerance Plus | +10% | |
| Dielectric Material Family | Ceramic | |
| Minimum Operating Temperature | -25°C | |
| Tolerance Minus | -10% | |
| Terminal Type | Solder | |
| Capacitor Family | Single Layer | |
| Maximum Operating Temperature | +125°C | |
Select all | ||
|---|---|---|
Brand RS PRO | ||
Capacitance 1nF | ||
Voltage 2kV dc | ||
Mounting Type Through Hole | ||
Tolerance ±10% | ||
Dielectric LR | ||
Diameter 10.5mm | ||
Tolerance Plus +10% | ||
Dielectric Material Family Ceramic | ||
Minimum Operating Temperature -25°C | ||
Tolerance Minus -10% | ||
Terminal Type Solder | ||
Capacitor Family Single Layer | ||
Maximum Operating Temperature +125°C | ||
- COO (Country of Origin):
- TW
Reduced heat dissipation permitted due to small dielectric loss of the ceramic material
Operating temperature range is guaranteed up to 125 degree C
Coated with flame-retardant epoxy resin
Halogen free products are available
Ideal for use on high frequency pulse circuits such as a horizontal resonance circuit for CTV and snubber circuits for switching power supplies
Operating temperature range is guaranteed up to 125 degree C
Coated with flame-retardant epoxy resin
Halogen free products are available
Ideal for use on high frequency pulse circuits such as a horizontal resonance circuit for CTV and snubber circuits for switching power supplies
