TE Connectivity Right Angle Male 5 way M12 to Straight Female 5 way M12 Sensor Actuator Cable, 1.5m
- RS Stock No.:
- 238-4590
- Mfr. Part No.:
- T4152AC9L25-003
- Brand:
- TE Connectivity
Bulk discount available
Subtotal (1 unit)*
£59.08
(exc. VAT)
£70.90
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 32 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 4 | £59.08 |
| 5 - 9 | £56.72 |
| 10 + | £54.83 |
*price indicative
- RS Stock No.:
- 238-4590
- Mfr. Part No.:
- T4152AC9L25-003
- Brand:
- TE Connectivity
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | TE Connectivity | |
| Series | M12 L-Code | |
| Cross Sectional Area | 1.5 mm² | |
| Sheath Colour | Grey | |
| Length | 1.5m | |
| Sheath Material | Nylon | |
| Connector 1 Gender | Male | |
| Connector 1 | M12 | |
| Connector 1 Number of Contacts | 5 | |
| Connector 1 Orientation | Right Angle | |
| Connector 2 Number of Contacts | 5 | |
| Connector 2 | M12 | |
| Connector 2 Gender | Female | |
| Connector 2 Housing Gender | Female | |
| Connector 2 Orientation | Straight | |
| Coding | L | |
| Voltage Rating | 63 V | |
| Current Rating | 12 A | |
| IP Rating | IP67 | |
| Conductor Material | Copper | |
| Maximum Operating Temperature | +85°C | |
| Standards Met | UL | |
| Insulation Material | PP | |
| Connector 1 Housing Gender | Male | |
| Number of Strands | 75 | |
| American Wire Gauge | 16 AWG | |
| Outer Diameter | 9.1mm | |
| Minimum Operating Temperature | -25°C | |
Select all | ||
|---|---|---|
Brand TE Connectivity | ||
Series M12 L-Code | ||
Cross Sectional Area 1.5 mm² | ||
Sheath Colour Grey | ||
Length 1.5m | ||
Sheath Material Nylon | ||
Connector 1 Gender Male | ||
Connector 1 M12 | ||
Connector 1 Number of Contacts 5 | ||
Connector 1 Orientation Right Angle | ||
Connector 2 Number of Contacts 5 | ||
Connector 2 M12 | ||
Connector 2 Gender Female | ||
Connector 2 Housing Gender Female | ||
Connector 2 Orientation Straight | ||
Coding L | ||
Voltage Rating 63 V | ||
Current Rating 12 A | ||
IP Rating IP67 | ||
Conductor Material Copper | ||
Maximum Operating Temperature +85°C | ||
Standards Met UL | ||
Insulation Material PP | ||
Connector 1 Housing Gender Male | ||
Number of Strands 75 | ||
American Wire Gauge 16 AWG | ||
Outer Diameter 9.1mm | ||
Minimum Operating Temperature -25°C | ||
- COO (Country of Origin):
- CN
The TE Connectivity M12 Power L-code cable assembly are an extension of the current M12 IEC standard and have been selected by PROFIBUS and PROFINET International as the standard for 24-volt power supply systems used in PROFINET devices. The M12 power cable assembly are available in both male and female connectors and suitable for every purpose with its conductor size from 1.5 mm² up to 2.5 mm² allowing for a more compact build of a high-power solutions for automation devices. The L-coding version is designed for DC power supplies with 63 V DC / 16 A, where a high current and low voltage is required making ideal for fieldbus Ethernet I/O boxes, Ethernet systems, network Devices, motors and drives and valve applications.
Unit remains protected and fully operational in most industrial applications
Secured signal connections and data transmission
Protection against mismatching with coded pin connector patterns
PNO approved for immediate implementation into PROFINET standard and embracing miniaturization of distribution boxes
One stop shop solution with broad product portfolio with cable jacket colours and material options
Secured signal connections and data transmission
Protection against mismatching with coded pin connector patterns
PNO approved for immediate implementation into PROFINET standard and embracing miniaturization of distribution boxes
One stop shop solution with broad product portfolio with cable jacket colours and material options
