TE Connectivity Straight Male 5 way M12 to Unterminated Sensor Actuator Cable, 1.5m

View all Sensor & Actuator Cables
Bulk discount available

Subtotal (1 unit)*

£42.03

(exc. VAT)

£50.44

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 24 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
1 - 4£42.03
5 - 9£40.36
10 +£39.01

*price indicative

RS Stock No.:
238-4506
Mfr. Part No.:
T41511C9L25-003
Brand:
TE Connectivity
Find similar products by selecting one or more attributes.
Select all

Brand

TE Connectivity

Series

M12 L-Code

Cross Sectional Area

1.5 mm²

Sheath Material

Nylon

Length

1.5m

Sheath Colour

Grey

Connector 1

M12

Connector 1 Orientation

Straight

Connector 1 Gender

Male

Connector 1 Number of Contacts

5

Connector 2

Unterminated

Coding

L

Voltage Rating

63 V

Current Rating

12 A

IP Rating

IP67

American Wire Gauge

16 AWG

Conductor Material

Copper

Outer Diameter

9.1mm

Minimum Operating Temperature

-25°C

Number of Strands

75

Maximum Operating Temperature

+85°C

Connector 1 Housing Gender

Male

Insulation Material

PP

Standards Met

UL

COO (Country of Origin):
CN
The TE Connectivity M12 Power L-code cable assembly are an extension of the current M12 IEC standard and have been selected by PROFIBUS and PROFINET International as the standard for 24-volt power supply systems used in PROFINET devices. The M12 power cable assembly are available in both male and female connectors and suitable for every purpose with its conductor size from 1.5 mm² up to 2.5 mm² allowing for a more compact build of a high-power solutions for automation devices. The L-coding version is designed for DC power supplies with 63 V DC / 16 A, where a high current and low voltage is required making ideal for fieldbus Ethernet I/O boxes, Ethernet systems, network Devices, motors and drives and valve applications.

Unit remains protected and fully operational in most industrial applications
Secured signal connections and data transmission
Protection against mismatching with coded pin connector patterns
PNO approved for immediate implementation into PROFINET standard and embracing miniaturization of distribution boxes
One stop shop solution with broad product portfolio with cable jacket colours and material options
