IXYS 1200 V 25 A Diode Fast Recovery 4-Pin SOT-227
- RS Stock No.:
- 920-0921
- Mfr. Part No.:
- DSEP2X25-12C
- Brand:
- IXYS
Bulk discount available
Subtotal (1 tube of 10 units)*
£236.54
(exc. VAT)
£283.85
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 10 unit(s) shipping from 18 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tube* |
|---|---|---|
| 10 - 10 | £23.654 | £236.54 |
| 20 - 40 | £22.708 | £227.08 |
| 50 + | £21.998 | £219.98 |
*price indicative
- RS Stock No.:
- 920-0921
- Mfr. Part No.:
- DSEP2X25-12C
- Brand:
- IXYS
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | IXYS | |
| Mount Type | Panel | |
| Product Type | Diode | |
| Package Type | SOT-227 | |
| Maximum Continuous Forward Current If | 25A | |
| Peak Reverse Repetitive Voltage Vrrm | 1200V | |
| Diode Configuration | Isolated | |
| Rectifier Type | Fast Recovery | |
| Pin Count | 4 | |
| Peak Non-Repetitive Forward Surge Current Ifsm | 250A | |
| Maximum Forward Voltage Vf | 5.92V | |
| Minimum Operating Temperature | -40°C | |
| Peak Reverse Current Ir | 2mA | |
| Maximum Operating Temperature | 150°C | |
| Peak Reverse Recovery Time trr | 70ns | |
| Standards/Approvals | No | |
| Length | 38.23mm | |
| Height | 12.22mm | |
| Automotive Standard | No | |
| Select all | ||
|---|---|---|
Brand IXYS | ||
Mount Type Panel | ||
Product Type Diode | ||
Package Type SOT-227 | ||
Maximum Continuous Forward Current If 25A | ||
Peak Reverse Repetitive Voltage Vrrm 1200V | ||
Diode Configuration Isolated | ||
Rectifier Type Fast Recovery | ||
Pin Count 4 | ||
Peak Non-Repetitive Forward Surge Current Ifsm 250A | ||
Maximum Forward Voltage Vf 5.92V | ||
Minimum Operating Temperature -40°C | ||
Peak Reverse Current Ir 2mA | ||
Maximum Operating Temperature 150°C | ||
Peak Reverse Recovery Time trr 70ns | ||
Standards/Approvals No | ||
Length 38.23mm | ||
Height 12.22mm | ||
Automotive Standard No | ||
- COO (Country of Origin):
- DE
Rectifier Diodes, Ixys
Diodes and Rectifiers, Ixys
