DiodesZetex 200 V Rectifier & Schottky Diode 3-Pin ITO-220S

View this category
Bulk discount available

Subtotal (1 tube of 50 units)*

£15.50

(exc. VAT)

£18.50

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 650 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Tube*
50 - 50£0.31£15.50
100 - 450£0.248£12.40
500 - 950£0.23£11.50
1000 +£0.20£10.00

*price indicative

RS Stock No.:
254-8776
Mfr. Part No.:
STPF1020CTSW
Brand:
DiodesZetex
Find similar products by selecting one or more attributes.
Select all

Brand

DiodesZetex

Product Type

Rectifier & Schottky Diode

Package Type

ITO-220S

Peak Reverse Repetitive Voltage Vrrm

200V

Series

STPF1020CTSW

Pin Count

3

Peak Non-Repetitive Forward Surge Current Ifsm

80A

Maximum Forward Voltage Vf

1.1V

Minimum Operating Temperature

-55°C

Maximum Operating Temperature

150°C

Standards/Approvals

RoHS

Height

29.65mm

Width

4.87 mm

Length

10.4mm

Automotive Standard

AEC-Q101

The DiodesZetex super fast glass passivated rectifier has superfast switching time for high efficiency. It has low forward voltage drop and high current capability. It has peak reverse voltage of 200 V and forward current of 10 A.

Glass passivated

Halogen and antimony free

Low reverse leakage current
