Infineon 30 V 200 mA Rectifier & Schottky Diode Schottky 2-Pin SOD-323
- RS Stock No.:
- 249-7000
- Mfr. Part No.:
- BAT5403WE6327HTSA1
- Brand:
- Infineon
Bulk discount available
View bulk pricing optionsSubtotal (1 reel of 3000 units)*
£216.00
(exc. VAT)
£258.00
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 24,000 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 3000 - 3000 | £0.072 | £216.00 |
| 6000 - 12000 | £0.068 | £204.00 |
| 15000 + | £0.064 | £192.00 |
*price indicative
- RS Stock No.:
- 249-7000
- Mfr. Part No.:
- BAT5403WE6327HTSA1
- Brand:
- Infineon
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Infineon | |
| Mount Type | Surface | |
| Product Type | Rectifier & Schottky Diode | |
| Package Type | SOD-323 | |
| Maximum Continuous Forward Current If | 200mA | |
| Peak Reverse Repetitive Voltage Vrrm | 30V | |
| Series | BAT54 | |
| Diode Configuration | Single | |
| Rectifier Type | Schottky | |
| Pin Count | 2 | |
| Minimum Operating Temperature | -65°C | |
| Maximum Forward Voltage Vf | 800mV | |
| Peak Non-Repetitive Forward Surge Current Ifsm | 600mA | |
| Peak Reverse Current Ir | 2μA | |
| Maximum Operating Temperature | 150°C | |
| Height | 1.25mm | |
| Standards/Approvals | RoHS | |
| Length | 2.5mm | |
| Width | 0.9mm | |
| Automotive Standard | AEC-Q101 | |
| Select all | ||
|---|---|---|
Brand Infineon | ||
Mount Type Surface | ||
Product Type Rectifier & Schottky Diode | ||
Package Type SOD-323 | ||
Maximum Continuous Forward Current If 200mA | ||
Peak Reverse Repetitive Voltage Vrrm 30V | ||
Series BAT54 | ||
Diode Configuration Single | ||
Rectifier Type Schottky | ||
Pin Count 2 | ||
Minimum Operating Temperature -65°C | ||
Maximum Forward Voltage Vf 800mV | ||
Peak Non-Repetitive Forward Surge Current Ifsm 600mA | ||
Peak Reverse Current Ir 2μA | ||
Maximum Operating Temperature 150°C | ||
Height 1.25mm | ||
Standards/Approvals RoHS | ||
Length 2.5mm | ||
Width 0.9mm | ||
Automotive Standard AEC-Q101 | ||
Infineon BAT54 Series Rectifier & Schottky Diode, 200mA Maximum Continuous Forward Current, 30V Peak Reverse Repetitive Voltage - BAT5403WE6327HTSA1
This rectifier & Schottky diode is a Compact semiconductor component designed for low-voltage rectification and fast switching in surface-mounted assemblies. It operates across a wide temperature span and is suitable for environments requiring low forward drop and minimal reverse leakage. The device conforms to lead-free restrictions and meets automotive-grade reliability standards for use in constrained footprints.
Features and Benefits:
• Low forward voltage of 800 mV for reduced conduction losses
• Continuous forward current rating 200 mA supports small-signal loads
• Peak reverse repetitive voltage 30 V for low-voltage protection circuits
• Peak non-repetitive surge 600 mA handles transient inrush events
• Peak reverse current 2 μA minimises leakage in standby conditions
• Operating range −65 °C to 150 °C enables high-temperature deployment
• Continuous forward current rating 200 mA supports small-signal loads
• Peak reverse repetitive voltage 30 V for low-voltage protection circuits
• Peak non-repetitive surge 600 mA handles transient inrush events
• Peak reverse current 2 μA minimises leakage in standby conditions
• Operating range −65 °C to 150 °C enables high-temperature deployment
Applications
• Suitable for power steering and sensor signal conditioning
• Ideal for battery protection in Compact devices
• Used with DC‑DC converters for output rectification
• Can be used for polarity protection in automotive modules
• Suitable for signal demodulation and clamping in mixed-signal boards
• Ideal for battery protection in Compact devices
• Used with DC‑DC converters for output rectification
• Can be used for polarity protection in automotive modules
• Suitable for signal demodulation and clamping in mixed-signal boards
What package type does it use for surface mounting?
It is supplied in a SOD‑323 package optimised for automated pick-and-place.
How many pins are available for PCB layout?
The component has two pins to accommodate simple diode connections.
What mounting method is recommended for assembly?
Surface-mount placement is specified for solder attachment on PCB pads.
Does it meet automotive qualification standards?
It complies with AEC‑Q101 for automotive semiconductor stress screening.
Is the device restricted by environmental substance regulations?
The part is RoHS-compliant, indicating adherence to lead-free material limits.
