Nexperia 100 V 3 A Rectifier & Schottky Diode Schottky Barrier 3-Pin CFP3

View this category

Subtotal (1 reel of 5000 units)*

£655.00

(exc. VAT)

£785.00

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 03 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Reel*
5000 +£0.131£655.00

*price indicative

RS Stock No.:
243-4834
Mfr. Part No.:
PMEG100T030ELPE-QZ
Brand:
Nexperia
Find similar products by selecting one or more attributes.
Select all

Brand

Nexperia

Product Type

Rectifier & Schottky Diode

Mount Type

Surface

Package Type

CFP3

Maximum Continuous Forward Current If

3A

Peak Reverse Repetitive Voltage Vrrm

100V

Series

PMEG

Diode Configuration

Single

Rectifier Type

Schottky Barrier

Pin Count

3

Peak Reverse Current Ir

3mA

Minimum Operating Temperature

-55°C

Peak Non-Repetitive Forward Surge Current Ifsm

100A

Maximum Forward Voltage Vf

710mV

Maximum Operating Temperature

175°C

Peak Reverse Recovery Time trr

12ns

Standards/Approvals

AEC-Q101

Automotive Standard

AEC-Q101

The Nexperia trench maximum efficiency general application (MEGA) schottky barrier rectifier is encapsulated in a CFP3 (SOD123W) small and flat lead surface-mounted device (SMD) with plastic package.

Low forward voltage

Low Qrr and low IRM

Low leakage current

High power capability due to clip-bonding technology

Small and flat lead SMD power plastic package

Qualified according to AEC-Q101 and recommended for use in automotive applications

High efficiency DC-to-DC conversion

Automotive LED lighting

Switch mode power supply

Freewheeling applications

Reverse polarity protection

OR-ing
