STMicroelectronics 1200 V 15 A Diode 2-Pin D2PAK STPSC15H12G2Y-TR
- RS Stock No.:
- 219-4239
- Mfr. Part No.:
- STPSC15H12G2Y-TR
- Brand:
- STMicroelectronics
Bulk discount available
Subtotal (1 pack of 2 units)*
£12.22
(exc. VAT)
£14.66
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 06 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 2 - 8 | £6.11 | £12.22 |
| 10 - 18 | £5.805 | £11.61 |
| 20 - 48 | £5.225 | £10.45 |
| 50 - 98 | £4.705 | £9.41 |
| 100 + | £4.465 | £8.93 |
*price indicative
- RS Stock No.:
- 219-4239
- Mfr. Part No.:
- STPSC15H12G2Y-TR
- Brand:
- STMicroelectronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | STMicroelectronics | |
| Product Type | Diode | |
| Mount Type | Surface | |
| Package Type | TO-263 | |
| Maximum Continuous Forward Current If | 15A | |
| Peak Reverse Repetitive Voltage Vrrm | 1200V | |
| Diode Configuration | Single | |
| Series | STPSC15H12G2Y-TR | |
| Pin Count | 2 | |
| Peak Reverse Current Ir | 45μA | |
| Maximum Forward Voltage Vf | 2.25V | |
| Minimum Operating Temperature | -40°C | |
| Peak Non-Repetitive Forward Surge Current Ifsm | 90A | |
| Maximum Operating Temperature | 175°C | |
| Length | 15.95mm | |
| Height | 4.3mm | |
| Width | 10.58 mm | |
| Standards/Approvals | No | |
| Automotive Standard | AEC-Q101 | |
| Select all | ||
|---|---|---|
Brand STMicroelectronics | ||
Product Type Diode | ||
Mount Type Surface | ||
Package Type TO-263 | ||
Maximum Continuous Forward Current If 15A | ||
Peak Reverse Repetitive Voltage Vrrm 1200V | ||
Diode Configuration Single | ||
Series STPSC15H12G2Y-TR | ||
Pin Count 2 | ||
Peak Reverse Current Ir 45μA | ||
Maximum Forward Voltage Vf 2.25V | ||
Minimum Operating Temperature -40°C | ||
Peak Non-Repetitive Forward Surge Current Ifsm 90A | ||
Maximum Operating Temperature 175°C | ||
Length 15.95mm | ||
Height 4.3mm | ||
Width 10.58 mm | ||
Standards/Approvals No | ||
Automotive Standard AEC-Q101 | ||
The STMicroelectronics 15 A, 1200 V Sic diode is an ultra-high performance power Schottky diode. It is manufactured using a silicon carbide substrate. The wide band gap material allows the design of a Schottky diode structure with a 1200 V rating. Due to the Schottky construction, no recovery is shown at turn-off and ringing patterns are negligible. The minimal capacitive turn-off behaviour is independent of temperature. Housed in D2PAK HV, this diode is perfectly suited for a usage in PFC applications, in OBC, DC/DC for EV, easing the compliance to IEC-60664-1.
AEC-Q101 qualified
No or negligible reverse recovery
Switching behaviour independent of temperature
Robust high voltage periphery
PPAP capable
Operating Tj from -40 °C to 175 °C
D²PAK HV creepage distance (anode to cathode) = 5.38 mm min.
ECOPACK2 compliant
