STMicroelectronics 1200V 10A, Rectifier & Schottky Diode, 2-Pin D2PAK HV STPSC10H12G2Y-TR
- RS Stock No.:
- 219-4233
- Mfr. Part No.:
- STPSC10H12G2Y-TR
- Brand:
- STMicroelectronics
Subtotal (1 reel of 1000 units)*
£3,311.00
(exc. VAT)
£3,973.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 05 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
---|---|---|
1000 + | £3.311 | £3,311.00 |
*price indicative
- RS Stock No.:
- 219-4233
- Mfr. Part No.:
- STPSC10H12G2Y-TR
- Brand:
- STMicroelectronics
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | STMicroelectronics | |
Mounting Type | Surface Mount | |
Package Type | D2PAK HV | |
Maximum Continuous Forward Current | 10A | |
Peak Reverse Repetitive Voltage | 1200V | |
Diode Configuration | Single | |
Pin Count | 2 | |
Number of Elements per Chip | 1 | |
Select all | ||
---|---|---|
Brand STMicroelectronics | ||
Mounting Type Surface Mount | ||
Package Type D2PAK HV | ||
Maximum Continuous Forward Current 10A | ||
Peak Reverse Repetitive Voltage 1200V | ||
Diode Configuration Single | ||
Pin Count 2 | ||
Number of Elements per Chip 1 | ||
The STMicroelectronics 10 A, 1200 V Sic diode is an ultra-high performance power Schottky diode. It is manufactured using a silicon carbide substrate. The wide band gap material allows the design of a Schottky diode structure with a 1200 V rating. Due to the Schottky construction, no recovery is shown at turn-off and ringing patterns are negligible. The minimal capacitive turn-off behaviour is independent of temperature. Housed in D2PAK HV, this diode is perfectly suited for a usage in PFC applications, in OBC, DC/DC for EV, easing the compliance to IEC-60664-1. The STPSC10H12G2Y-TR will boost performances in hard switching conditions. Its high forward surge capability ensures good robustness during transient phases.
AEC-Q101 qualified
No or negligible reverse recovery
Switching behaviour independent of temperature
Robust high voltage periphery
PPAP capable
Operating Tj from -40 °C to 175 °C
Low VF
No or negligible reverse recovery
Switching behaviour independent of temperature
Robust high voltage periphery
PPAP capable
Operating Tj from -40 °C to 175 °C
Low VF
