Vishay 600 V 4 A Rectifier & Schottky Diode Standard 7-Pin DFN33A SE40N3J-M3/I
- RS Stock No.:
- 277-579
- Mfr. Part No.:
- SE40N3J-M3/I
- Brand:
- Vishay
Subtotal (1 reel of 6000 units)*
£1,188.00
(exc. VAT)
£1,428.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 12,000 unit(s) shipping from 02 February 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 6000 + | £0.198 | £1,188.00 |
*price indicative
- RS Stock No.:
- 277-579
- Mfr. Part No.:
- SE40N3J-M3/I
- Brand:
- Vishay
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Vishay | |
| Product Type | Rectifier & Schottky Diode | |
| Mount Type | Surface | |
| Package Type | DFN33A | |
| Maximum Continuous Forward Current If | 4A | |
| Peak Reverse Repetitive Voltage Vrrm | 600V | |
| Diode Configuration | Single | |
| Series | SE40N3 | |
| Rectifier Type | Standard | |
| Pin Count | 7 | |
| Minimum Operating Temperature | -55°C | |
| Peak Non-Repetitive Forward Surge Current Ifsm | 70A | |
| Peak Reverse Current Ir | 5μA | |
| Maximum Forward Voltage Vf | 1.5V | |
| Maximum Operating Temperature | 175°C | |
| Width | 2.23 mm | |
| Length | 3.4mm | |
| Standards/Approvals | JESD 201 Class 2, AEC-Q101 | |
| Height | 0.98mm | |
| Automotive Standard | AEC-Q101 | |
| Select all | ||
|---|---|---|
Brand Vishay | ||
Product Type Rectifier & Schottky Diode | ||
Mount Type Surface | ||
Package Type DFN33A | ||
Maximum Continuous Forward Current If 4A | ||
Peak Reverse Repetitive Voltage Vrrm 600V | ||
Diode Configuration Single | ||
Series SE40N3 | ||
Rectifier Type Standard | ||
Pin Count 7 | ||
Minimum Operating Temperature -55°C | ||
Peak Non-Repetitive Forward Surge Current Ifsm 70A | ||
Peak Reverse Current Ir 5μA | ||
Maximum Forward Voltage Vf 1.5V | ||
Maximum Operating Temperature 175°C | ||
Width 2.23 mm | ||
Length 3.4mm | ||
Standards/Approvals JESD 201 Class 2, AEC-Q101 | ||
Height 0.98mm | ||
Automotive Standard AEC-Q101 | ||
- COO (Country of Origin):
- CN
The Vishay Standard Rectifier in a DFN33A package provides reliable power line polarity protection and rail to rail protection in consumer, industrial, and automotive applications. With halogen free, RoHS compliant materials and AEC Q101 qualification, it ensures high performance operation across a wide temperature range of 55°C to +175°C. The rectifier features matte tin plated leads for easy soldering and robust durability.
Leadless DFN package with side wettable flanks suitable for customer AOI
Ideal for automated placement
Oxide Planar chip junction
Low forward voltage drop
ESD capability
AEC Q101 qualified
