FAG NJ204-E-XL-TVP2-C3 20mm I.D Cylindrical Roller Bearing, 47mm O.D
- RS Stock No.:
- 194-7334
- Mfr. Part No.:
- NJ204-E-XL-TVP2-C3
- Brand:
- FAG
Bulk discount available
Subtotal (1 unit)*
£36.32
(exc. VAT)
£43.58
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 21 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £36.32 |
5 - 9 | £34.87 |
10 - 24 | £34.13 |
25 + | £33.40 |
*price indicative
- RS Stock No.:
- 194-7334
- Mfr. Part No.:
- NJ204-E-XL-TVP2-C3
- Brand:
- FAG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | FAG | |
Inside Diameter | 20mm | |
Outside Diameter | 47mm | |
Roller Bearing Type | Cylindrical | |
Race Width | 14mm | |
Bore Type | Parallel | |
Static Load Rating | 24700N | |
Number of Rows | 1 | |
Dynamic Load Rating | 32500N | |
End Type | Open | |
Fatigue Limit Load | 3950N | |
Select all | ||
---|---|---|
Brand FAG | ||
Inside Diameter 20mm | ||
Outside Diameter 47mm | ||
Roller Bearing Type Cylindrical | ||
Race Width 14mm | ||
Bore Type Parallel | ||
Static Load Rating 24700N | ||
Number of Rows 1 | ||
Dynamic Load Rating 32500N | ||
End Type Open | ||
Fatigue Limit Load 3950N | ||
Single row cylindrical roller bearings with cage are suitable where:
Bearing arrangements are subjected to very high radial loads
Not only high radial forces but also axial loads from one or both directions must be supported by the bearing position (semi-locating or locating bearing function)
Bearing arrangements must have very high rigidity
Axial displacements of the shaft relative to the housing must be compensated without constraint in the bearing (in the case of bearings with a non-locating or semi-locating bearing function)
High radial loads and very high speeds occur but the very high radial load carrying capacity of full complement cylindrical roller bearings is not required
The bearings should be separable (one bearing ring can be removed) for easier mounting
Bearing arrangements are subjected to very high radial loads
Not only high radial forces but also axial loads from one or both directions must be supported by the bearing position (semi-locating or locating bearing function)
Bearing arrangements must have very high rigidity
Axial displacements of the shaft relative to the housing must be compensated without constraint in the bearing (in the case of bearings with a non-locating or semi-locating bearing function)
High radial loads and very high speeds occur but the very high radial load carrying capacity of full complement cylindrical roller bearings is not required
The bearings should be separable (one bearing ring can be removed) for easier mounting
