SKF 21317 EK/C3 Tapered 1:12 85 mm ID Roller Bearing, 180 mm OD
- RS Stock No.:
- 460-618
- Mfr. Part No.:
- 21317 EK/C3
- Brand:
- SKF
Subtotal (1 unit)*
£374.64
(exc. VAT)
£449.57
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 22 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £374.64 |
*price indicative
- RS Stock No.:
- 460-618
- Mfr. Part No.:
- 21317 EK/C3
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Roller Bearing | |
| Inside Diameter | 85mm | |
| Race Width | 41mm | |
| Bore Type | Tapered 1:12 | |
| Cage Material | Sheet Metal | |
| Outside Diameter | 180mm | |
| Internal Clearance | C3 | |
| Static Load Rating | 375kN | |
| Number of Rows | 2 | |
| Dynamic Load Rating | 331kN | |
| Standards/Approvals | RoHS | |
| Series | 21317 EK/C3 | |
| Limiting Speed | 5300rpm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Roller Bearing | ||
Inside Diameter 85mm | ||
Race Width 41mm | ||
Bore Type Tapered 1:12 | ||
Cage Material Sheet Metal | ||
Outside Diameter 180mm | ||
Internal Clearance C3 | ||
Static Load Rating 375kN | ||
Number of Rows 2 | ||
Dynamic Load Rating 331kN | ||
Standards/Approvals RoHS | ||
Series 21317 EK/C3 | ||
Limiting Speed 5300rpm | ||
Omkar
The SKF Precision-engineered spherical roller bearing is designed for demanding applications where reliability and performance are paramount. Manufactured with high-quality materials, it ensures optimal support yet accommodates misalignments, making it ideal for sophisticated machinery and heavy-duty operations. The advanced design promotes enhanced operational efficiency and longevity, ensuring that machinery can operate smoothly under varying loads and speeds. With its robust construction, this bearing copes brilliantly in challenging environments, delivering sound performance and resilience.
Engineered for extended service life in demanding conditions
Optimised to reduce friction and enhance energy efficiency
Designed with a spherical design for better alignment capabilities
Facilitates easy installation and maintenance, saving time
Manufactured to withstand high radial and axial loads
