SKF 21310 EK/C3 Tapered 1:12 50 mm ID Roller Bearing, 110 mm OD
- RS Stock No.:
- 461-110
- Mfr. Part No.:
- 21310 EK/C3
- Brand:
- SKF
Subtotal (1 unit)*
£151.47
(exc. VAT)
£181.76
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 + | £151.47 |
*price indicative
- RS Stock No.:
- 461-110
- Mfr. Part No.:
- 21310 EK/C3
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Roller Bearing | |
| Inside Diameter | 50mm | |
| Race Width | 27mm | |
| Bore Type | Tapered 1:12 | |
| Cage Material | Sheet Metal | |
| Limiting Speed | 7500rpm | |
| Outside Diameter | 110mm | |
| Dynamic Load Rating | 159kN | |
| Standards/Approvals | RoHS | |
| Static Load Rating | 166kN | |
| Internal Clearance | C3 | |
| Series | 21310 EK/C3 | |
| Number of Rows | 2 | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Roller Bearing | ||
Inside Diameter 50mm | ||
Race Width 27mm | ||
Bore Type Tapered 1:12 | ||
Cage Material Sheet Metal | ||
Limiting Speed 7500rpm | ||
Outside Diameter 110mm | ||
Dynamic Load Rating 159kN | ||
Standards/Approvals RoHS | ||
Static Load Rating 166kN | ||
Internal Clearance C3 | ||
Series 21310 EK/C3 | ||
Number of Rows 2 | ||
- COO (Country of Origin):
- GB
Omkar
The SKF Spherical roller bearing is expertly engineered to withstand the most demanding applications, ensuring high load capacity and reliability. This bearing design facilitates self-alignment, accommodating minor shaft misalignments while maintaining optimal performance. Constructed with high-quality materials, it boasts excellent wear resistance and extended operational life. The spherical roller design permits angular deflection, allowing for enhanced performance even under challenging conditions. With its robust construction, this bearing is ideal for applications in various industries, from heavy machinery to automotive components, thereby providing versatility and dependability.
Self-aligning properties minimise the impact of misalignment
Robust construction enhances durability and resistance to wear
Angular deflection capability accommodating operational flexibility
Versatile for use in a variety of industrial applications
