NTN 22308EMW33 Round 40 mm I.D Spherical Roller Bearing, 90 mm O.D
- RS Stock No.:
- 454-322
- Mfr. Part No.:
- 22308EMW33
- Brand:
- NTN
Subtotal (1 unit)*
£123.96
(exc. VAT)
£148.75
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 12 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £123.96 |
*price indicative
- RS Stock No.:
- 454-322
- Mfr. Part No.:
- 22308EMW33
- Brand:
- NTN
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | NTN | |
| Product Type | Spherical Roller Bearing | |
| Inside Diameter | 40 mm | |
| Race Width | 33mm | |
| Bore Type | Round | |
| Roller Material | Steel | |
| Cage Material | Steel | |
| Outside Diameter | 90 mm | |
| Dynamic Load Rating | 169kN | |
| End Type | Open | |
| Limiting Speed | 7400rpm | |
| Standards/Approvals | RoHS | |
| Maximum Speed - Oil | 6600rpm | |
| Maximum Speed - Grease | 5400rpm | |
| Bearing Material | Through Hardened Steel | |
| Number of Rows | 2 | |
| Static Load Rating | 152kN | |
| Series | EMW33 | |
| Internal Clearance | CN | |
| Select all | ||
|---|---|---|
Brand NTN | ||
Product Type Spherical Roller Bearing | ||
Inside Diameter 40 mm | ||
Race Width 33mm | ||
Bore Type Round | ||
Roller Material Steel | ||
Cage Material Steel | ||
Outside Diameter 90 mm | ||
Dynamic Load Rating 169kN | ||
End Type Open | ||
Limiting Speed 7400rpm | ||
Standards/Approvals RoHS | ||
Maximum Speed - Oil 6600rpm | ||
Maximum Speed - Grease 5400rpm | ||
Bearing Material Through Hardened Steel | ||
Number of Rows 2 | ||
Static Load Rating 152kN | ||
Series EMW33 | ||
Internal Clearance CN | ||
- COO (Country of Origin):
- IT
The NTN Spherical Roller Bearing is designed for superior performance and reliability in various applications. Manufactured to the highest standards by ntn, it boasts exceptional load-bearing capabilities and enhanced durability. With its internal diameter of 40 mm and external diameter of 90 mm, this bearing ensures a perfect fit, making it suitable for a wide range of industrial uses. The unique design features a mass of 1.021 kg, ensuring robust operation even under demanding conditions. The bearing's high dynamic load rating of 169 kN and static load rating of 152 kN speak to its ability to handle substantial stress and pressures, while the cleverly designed lubrication system with three holes optimises maintenance. With a wide operational temperature range from -40 °C to 200 °C, this product excels in challenging environments. Choose this bearing to guarantee smooth operation and longevity in your machinery.
Designed for high load capacities to support dynamic applications
Optimised for efficient lubrication to reduce maintenance needs
Built with precision engineering for reliable performance
Capable of operating in extreme temperatures for versatility
Manufactured with top-grade materials for enhanced longevity
Supports various industrial applications with its robust design
