FAG NJ2311-E-XL-TVP2-C3 55 mm ID Cylindrical Roller Bearing, 120 mm OD
- RS Stock No.:
- 312-988
- Mfr. Part No.:
- NJ2311-E-XL-TVP2-C3
- Brand:
- FAG
Subtotal (1 unit)*
£189.78
(exc. VAT)
£227.74
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 07 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £189.78 |
*price indicative
- RS Stock No.:
- 312-988
- Mfr. Part No.:
- NJ2311-E-XL-TVP2-C3
- Brand:
- FAG
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | FAG | |
| Product Type | Cylindrical Roller Bearing | |
| Inside Diameter | 55 mm | |
| Race Width | 43mm | |
| Cage Material | Polyamide 66 | |
| Internal Clearance | CN | |
| Dynamic Load Rating | 235000N | |
| Standards/Approvals | No | |
| Number of Rows | 1 | |
| Outside Diameter | 120 mm | |
| Static Load Rating | 230000N | |
| Limiting Speed | 8000rpm | |
| Select all | ||
|---|---|---|
Brand FAG | ||
Product Type Cylindrical Roller Bearing | ||
Inside Diameter 55 mm | ||
Race Width 43mm | ||
Cage Material Polyamide 66 | ||
Internal Clearance CN | ||
Dynamic Load Rating 235000N | ||
Standards/Approvals No | ||
Number of Rows 1 | ||
Outside Diameter 120 mm | ||
Static Load Rating 230000N | ||
Limiting Speed 8000rpm | ||
RoHS Status: Exempt
- COO (Country of Origin):
- RO
The FAG Cylindrical Roller Bearing is a single row, semi locating bearing designed to support both radial and axial loads. It features a cage that keeps the rollers properly aligned for smooth operation. This bearing has two ribs on the outer ring and one rib on the inner ring, ensuring effective load distribution and increased stability.
Radial load
Axial load in one direction
Grease lubrication
Oil lubrication
Not sealed
