SKF M58 x 1.5 in Steel Rod End, 60 mm Bore Metric
- RS Stock No.:
- 463-261
- Mfr. Part No.:
- SIR 60 ES
- Brand:
- SKF
Subtotal (1 unit)*
£579.64
(exc. VAT)
£695.57
(inc. VAT)
Add 1 unit to get free delivery
Temporarily out of stock
- Shipping from 20 March 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £579.64 |
*price indicative
- RS Stock No.:
- 463-261
- Mfr. Part No.:
- SIR 60 ES
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Connection Size | M58 x 1.5 in | |
| Product Type | Rod End | |
| Bore Size | 60 mm | |
| Material | Steel | |
| Dynamic Load Rating | 245kN | |
| Static Load Rating | 325kN | |
| Thread Standard | Metric | |
| Outside Diameter | 132 mm | |
| Standards/Approvals | No | |
| Overall Width | 44mm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Connection Size M58 x 1.5 in | ||
Product Type Rod End | ||
Bore Size 60 mm | ||
Material Steel | ||
Dynamic Load Rating 245kN | ||
Static Load Rating 325kN | ||
Thread Standard Metric | ||
Outside Diameter 132 mm | ||
Standards/Approvals No | ||
Overall Width 44mm | ||
- COO (Country of Origin):
- DE
The SKF Rod ends contain a spherical plain bearing with a steel/steel sliding contact surface combination. The bearing requires maintenance and can be relubricated via grease fitting in the housing and via the shaft. The female thread is available with a left- or right-hand thread.
Easy to relubricate
Simple and ready to mount
Slotted shank with clamping screws
Suitable for hydraulic cylinders
Bearing can be exchanged
