3M 3759 Series Flat Cable, Round, 1.27 mm Pitch, 34, 30 m Length
- RS Stock No.:
- 192-5017
- Distrelec Article No.:
- 155-63-674
- Mfr. Part No.:
- 3759-34
- Brand:
- 3M
Subtotal (1 reel of 30 metres)*
£287.40
(exc. VAT)
£345.00
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 60 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 30 + | £9.58 | £287.40 |
*price indicative
- RS Stock No.:
- 192-5017
- Distrelec Article No.:
- 155-63-674
- Mfr. Part No.:
- 3759-34
- Brand:
- 3M
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | 3M | |
| Product Type | Flat Cable | |
| Cable Type | Round | |
| Pitch | 1.27mm | |
| Voltage | 300V | |
| Screened/Unscreened | Unscreened | |
| Number of Conductors | 34 | |
| American Wire Gauge | 28AWG | |
| Jacket Material | Polyvinyl Chloride | |
| Conductor Type | Round | |
| Series | 3759 | |
| Cable Length | 30m | |
| Standards/Approvals | UL | |
| Hi-Flex | No | |
| Jacket Colour | Black | |
| Fire Behaviour | FT1 | |
| Number of Strands | 7 | |
| Conductor Material | Tin Copper Wire | |
| Minimum Operating Temperature | -20°C | |
| Core Strands | 7 x 36AWG | |
| Maximum Operating Temperature | 80°C | |
| Size of Strands | 36AWG | |
| Select all | ||
|---|---|---|
Brand 3M | ||
Product Type Flat Cable | ||
Cable Type Round | ||
Pitch 1.27mm | ||
Voltage 300V | ||
Screened/Unscreened Unscreened | ||
Number of Conductors 34 | ||
American Wire Gauge 28AWG | ||
Jacket Material Polyvinyl Chloride | ||
Conductor Type Round | ||
Series 3759 | ||
Cable Length 30m | ||
Standards/Approvals UL | ||
Hi-Flex No | ||
Jacket Colour Black | ||
Fire Behaviour FT1 | ||
Number of Strands 7 | ||
Conductor Material Tin Copper Wire | ||
Minimum Operating Temperature -20°C | ||
Core Strands 7 x 36AWG | ||
Maximum Operating Temperature 80°C | ||
Size of Strands 36AWG | ||
3M 3759 Series Flat Cable, 30m Length, 34 Conductors - 3759-34
This flat cable provides a compact, multi‑conductor interconnect for high‑density wiring applications, designed to link board‑level connectors and harnesses in industrial and electronic systems. It is constructed with multiple round conductors in a slim profile and enclosed in a flexible black PVC outer layer suitable for routine electrical installations.
Features and Benefits:
• 34 conductors enable dense signal routing in limited space
• 28 AWG tin‑plated copper round conductors offer good conductivity and solderability
• 7‑strand cores deliver improved Flex performance over solid wire
• 1.27mm pitch supports close‑pitch connector interfaces
• Rated to 300V for low‑voltage control and signal circuits
• Operates between -20 °C and 80 °C for standard industrial environments
• 28 AWG tin‑plated copper round conductors offer good conductivity and solderability
• 7‑strand cores deliver improved Flex performance over solid wire
• 1.27mm pitch supports close‑pitch connector interfaces
• Rated to 300V for low‑voltage control and signal circuits
• Operates between -20 °C and 80 °C for standard industrial environments
Applications
• Suitable for ribbon‑to‑board connections on control panels
• Ideal for cable runs between sensors and PLCs in automation
• Used with high‑density connector arrays on test rigs
• Can be used for inter‑module wiring in mechanical assemblies
• Used for factory equipment signal harnessing over moderate lengths
• Ideal for cable runs between sensors and PLCs in automation
• Used with high‑density connector arrays on test rigs
• Can be used for inter‑module wiring in mechanical assemblies
• Used for factory equipment signal harnessing over moderate lengths
How is the conductor assembly constructed to aid flexing?
Each conductor comprises seven fine strands of tin‑plated copper, which increases flexibility compared with single‑strand cores and reduces fatigue in bending applications.
Is the cable screened for EMI protection?
No, the cable is unscreened, so additional shielding should be provided externally where electromagnetic immunity is required.
How long is the cable supply and how does length affect installations?
The product is supplied in a continuous 30 m length, allowing long runs without joints
installers should consider voltage drop and termination routing for signal integrity.
What is the outer material and how does it behave in typical environments?
The jacket is polyvinyl chloride in black, providing mechanical protection and Basic chemical resistance suitable for standard indoor industrial settings.
Which fire performance rating does the cable meet and what does that imply?
The cable meets FT1 fire behaviour criteria, indicating limited flame propagation suited to applications where reduced vertical flame spread is required.
Approvals
UL and CSA
