Keysight Technologies RF Switch, 2.4 mm Female Connector SPDT, 50 GHz Max, 60 dB Isolation, 15000000 ns, 50Ω Output
- RS Stock No.:
- 223-7220
- Mfr. Part No.:
- 87222E
- Brand:
- Keysight Technologies
Subtotal (1 unit)*
£3,352.00
(exc. VAT)
£4,022.40
(inc. VAT)
Add 1 unit to get free delivery
Temporarily out of stock
- Shipping from 27 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £3,352.00 |
*price indicative
- RS Stock No.:
- 223-7220
- Mfr. Part No.:
- 87222E
- Brand:
- Keysight Technologies
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Keysight Technologies | |
| Product Type | RF Switch | |
| Switching Speed | 15000000ns | |
| Port to Port Isolation | 60dB | |
| Maximum Insertion Loss | 1.15dB | |
| Contact Configuration | SPDT | |
| Connector Type | 2.4 mm Female | |
| Output Impedance | 50Ω | |
| Height | 62.73mm | |
| Minimum Operating Temperature | -25°C | |
| Contact Current | 200mA | |
| Contact DC Voltage | 24V | |
| Length | 31.75mm | |
| Maximum Operating Temperature | 75°C | |
| Standards/Approvals | DEKRA Approval | |
| Maximum Frequency | 50GHz | |
| Series | 87222x | |
| Minimum Frequency | 0Hz | |
| Width | 33.5 mm | |
| Select all | ||
|---|---|---|
Brand Keysight Technologies | ||
Product Type RF Switch | ||
Switching Speed 15000000ns | ||
Port to Port Isolation 60dB | ||
Maximum Insertion Loss 1.15dB | ||
Contact Configuration SPDT | ||
Connector Type 2.4 mm Female | ||
Output Impedance 50Ω | ||
Height 62.73mm | ||
Minimum Operating Temperature -25°C | ||
Contact Current 200mA | ||
Contact DC Voltage 24V | ||
Length 31.75mm | ||
Maximum Operating Temperature 75°C | ||
Standards/Approvals DEKRA Approval | ||
Maximum Frequency 50GHz | ||
Series 87222x | ||
Minimum Frequency 0Hz | ||
Width 33.5 mm | ||
- COO (Country of Origin):
- MY
The Keysight Technologies multiport coaxial switch improves insertion loss repeatability and isolation, which is necessary for higher performance test systems. It has 4 port switch configuration.
High reliability and exceptional repeatability ensure excellent measurement accuracy
Excellent RF specifications optimize your test system measurement capability
Broad selection of switches provides configuration flexibility for various applications
Note
Manufacturer’s Warranty
